1.5 System Specifications

System
CPU
FSB
BIOS
System Chipset
I/O Chip
System Memory
SSD
Watchdog Timer
H/W Status Monitor
Expansion
I/O
MIO
IrDA
USB
Display
Chipset
Display Memory
Resolution
VGA/LCD Interface
LVDS
Audio
Chipset
AC97 Codec
Audio Interface
Onboard VIA Eden ESP6000 667 MHz
Note: Available in different CPU speeds by request
66/100/133 MHz
Award 256 KB Flash BIOS
VIA TwisterT VT8606/VT82C686B
VIA VT82C686B / Windbond W83977EF
Onboard 128 MB SDRAM (32/64 MB by request)
One CompactFlash Type I/II socket
Reset: 32 sec.~254 min., 1 min./step
Monitoring system temperature, voltage, and cooling fan status. Auto
throttling control when CPU overheats.
One PC/104 connector
2 x EIDE (Ultra DMA 100), 1 x LPT, 3 x RS-232, 1x RS-232/422/485, 1 x
K/B & Mouse
115k bps, IrDA 1.0 compliant
2 USB 1.1 ports
VIA VT8606 TwisterT with integrated 2D/3D graphics engine
8/16/32 MB frame buffer using system memory
CRT mode: 1280 x 1024 @ 32 bpp (85 Hz)
LCD/Simultaneous mode: 1280 x 1024 @ 32 bpp (85 Hz)
AGP 4x VGA/LCD interface
VIA VT8606 supports dual-channel 18-bit LVDS panels
VIA VT82C686B
VIA VT1612A
Mic in, Line in, CD Audio in, Line out
User's Manual
ECM-3612 User's Manual 13
