MAINTENANCE

Remove the Electro-Well from the heating system every five years and clean any scale or sediment deposits from all parts that are
exposed to the boiler water. After cleaning, reinstall the well using pipe sealing compound. Teflon tape is not recommended.
REMOTE MOUNTING KITS
Part No. Description
48-101
HydroStat Remote Mount Kit with 24" sensor
48-102
HydroStat Remote Mount Kit with 48" sensor
ELECTRO-WELLS
We warrant products manufactured by Hydrolevel Company to be free from defects in
material and workmanship for a period of two years from the date of manufacture or
one year from the date of installation, whichever occurs first. In the event of any claim
under this warranty or otherwise with respect to our products which is made within
such period, we will, at our option, repair or replace such products or refund the pur-
chase price paid to us by you for such products. In no event shall Hydrolevel Company
83 Water Street • New Haven, CT 06511 • Phone (203) 776-0473 • FAX (203) 773-1019 •
DIMENSIONS

SPECIFICATIONS

Input voltage
Burner contacts
Circulator contacts
Operating range – low limit
Operating range – high limit
LIMITED MANUFACTURERʼS WARRANTY
Part No. Description
48-103
HydroStat Remote Mount Kit with 10' sensor
48-104
HydroStat Remote Mount Kit with 20' sensor
FUEL SMART HYDROSTAT MODEL 3200
120 VAC, 60 HZ
30 VA@24 VAC
5.8 FLA, 34.8 LRA@120 VAC
Off or 110°F - 200°F
100°F - 220°F
be liable for any other loss or damage, whether direct, indirect, incidental or conse-
quential. This warranty is your EXCLUSIVE remedy and shall be IN PLACE OF any other
warranty or guarantee, express or implied, including, without limitation, any warranty
of MERCHANTABILITY or fitness for a particular purpose. This warranty may not be
assigned or transferred and any unauthorized transfer or assignment thereof shall be
void and of no force or effect.
