AUDIO AND CONNECTIVITY
Learn how to operate the vehicle's audio system.
Basic Audio Operation
Connect audio devices and operate buttons and displays for the audio system.
USB Port
1. Open the USB cover in the front console.
2. Insert a USB flash drive or other audio device,
such as an iPod
An additional USB port is located inside the center
console.*
Accessory Power Socket
Open the socket cover in the front console to use
power when the vehicle is on.
An additional power socket is located inside the
center console.*
NOTICE
Do not insert an automotive type cigarette lighter element. This can overheat
the power socket.
HDMI Port*
1. Open the HDMI cover in the front console.
2. Insert an HDMI cable into the HDMI port.
or iPhone
, into the USB port.
®
®
State, provincial, or local laws may prohibit the operation
of handheld electronic devices while operating a vehicle.
AUDIO AND CONNECTIVITY
iPod and iPhone are trademarks of Apple, Inc.
Additional cables and connectors sold separately.
*if equipped
