Summary of Contents for Eraser L Series
- Page 1 Please Read Before Operating Unit MODEL L (SERIES) WIRE STRIPPERS & LEAD CLEANERS Please Call for Service or Spare Parts Phone: (315) 454-3237 Fax: (315) 454-3090 The Eraser Company, Inc. Website: www.eraser.com PO Box 4961 E-mail: info@eraser.com Syracuse, NY 13221, USA...
- Page 2 L4 ........... 1-3/4” diameter x 8-1/4” long (44mmø x 210mm) Weight L2S, L2AS, PL3S ..........11 lbs. (5 Kg) L4 ..............2 lbs. (910g) MODEL L4 MODEL PL3S Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • info@eraser.com • www.eraser.com • Fax 315-454-3090...
- Page 3 20-16 AWG (081-1.30mmø) L31CC-IR9027 L31CF-IR9028 L31CB-IR9029 15-13 AWG (1.45-1.83mmø) L33CC-IR9037 L33CF-IR9038 L33CB-IR9039 13-11 AWG (1.83-2.31mmø) L38CC-IR9047 L38CF-IR9048 L38CB-IR9049 L2S IR0104 11-9 AWG (2.31-2.90mmø) L34CC-IR9057 L34CF-IR9058 Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • info@eraser.com • www.eraser.com • Fax 315-454-3090...
- Page 4 TO REDUCE THE RISKS OF FIRE, ELECTRIC SHOCK, are removed from machine before turning it on. AND PERSONAL INJURY, AND DEATH. Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • info@eraser.com • www.eraser.com • Fax 315-454-3090...
- Page 5 After replacing the collet assembly and guards on the rod to the desired position using the smaller of the unit, connect the unit to the power supply. Allen wrenches provided. Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • info@eraser.com • www.eraser.com • Fax 315-454-3090...
- Page 6 Model L4 The L4 unit should be lubricated DAILY with a turbine or spindle grade oil containing a rust inhibitor with a Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • info@eraser.com • www.eraser.com • Fax 315-454-3090...
- Page 7 L SERIES MODEL WIRE STRIPPERS & LEAD CLEANERS OPERATING MANUAL TROUBLE SHOOTING: PROBLEM: Wire does not strip SOLUTIONS: 1) Check that insert size is correct for wire being stripped. 2) Tighten collet on insert. 3) Check that slots of insert are aligned with slots of collet.
