IQ JoinGroup AVS200 Quick Manual

JoinGroup AVS200
1 2
3 C

Packing List

1.Speakerphone
1 2
3 C
3.Hub
5.5m DIN6 Cable * 2 pcs
7.Power supply
Camera
1 2
1.Status indicator
2.Power indicator
3.DIN6 Cable port
Quick Guide
2.Camera
4.Remote Control
6.3m USB cable *1 pcs
3

Attentions

How to Use

To prevent damage to this product or any product connected to it, this product can only
be used within the specified range.
Do not expose the product to rain or moisture.
To prevent the risk of electric shock, do not open the case. Installation and maintenance
should only be carried out by qualified technicians.
Do not use the product beyond the specified temperature, humidity or power supply
specifications.
Wipe it with a soft, dry cloth when cleaning the camera lens. Wipe it gently with a mild
detergent if needed. Do not use strong or corrosive detergents to avoid scratching the
lens and affecting the image.

Install with Caution

Do not rotate the camera head violently, otherwise it may cause mechanical failure.
This product should be placed on a stable desktop or other horizontal surface. Do not
install the product obliquely, otherwise it may display inclined image.
Housing of this product is made of organic materials. Do not expose it to any liquid, gas
or solids which may corrode the shell.
Ensure there are no obstacles within rotation range of the holder.
Do not power on before completing installation.

Product Overview

Speakerphone
4
1 2 3
1.Optional expansion microphone port 1
2.Optional expansion microphone port 2
3.DIN6 cable port
4.LED Status indicator
5.Bluetooth indicator
6.Function keys
7.Volume indicator
Hub
3
4
2
1
1. DIN6 Cable port
2. USB port
3. Power port
4. Turn on/off
5. Status indicator
7
6
1 2
3 C
5
5
