TP368 Early Fun Tower
TP369 Early Fun Play Centre
INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE.
PLEASE RETAIN FOR FUTURE REFERENCE.
TP368 Early Fun Tower
IMPORTANT
These instructions must be followed for safe assembly and use. Please retain for future reference.
WARNING!
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED.
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN UNDER 36 MONTHS
UNTIL FULLY ASSEMBLED.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE. ADULT SUPERVISION IS REQUIRED.
WARNING: THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 18 MONTHS+.
WARNING: MAXIMUM COMBINED USER WEIGHT 100KGS
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST BE FITTED BEFORE USE.
TP913X FoldAway Swing Seat
WARNING: THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 6 MONTHS TO 3 YEARS.
WARNING : MAXIMUM USER WEIGHT 45KGS
TP369 Early Fun Play Centre
Sand not included
1 Person
Assembly Build
Recommended

Advertisement

loading
Need help?

Need help?

Do you have a question about the TP368 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for active fun TP368

Summary of Contents for active fun TP368

  • Page 1 TP368 Early Fun Tower TP369 Early Fun Play Centre INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE. PLEASE RETAIN FOR FUTURE REFERENCE. TP368 Early Fun Tower TP369 Early Fun Play Centre Sand not included IMPORTANT These instructions must be followed for safe assembly and use. Please retain for future reference.
