Overhead door STANLEY Quick Start Manual

Overhead Door Company
of Cedar Rapids & Iowa City
Always disconnect operator from door before programming
to avoid injury to yourself or the operator
STANLEY • Wireless Codekey Entry System
To Select Radio Code: Determine the Radio Code set on the opener
received. Panel may be either 9 or 10 dip switches, or 5-code wires,
located at the rear of the opener.

10 Dip Switches

1. Note the numbers of each dip switch in the ON (closed)
position. Use the ones already selected or select new settings.
This will be the new "Radio Code".See Figure C.
2. Press the "RADIO LEARN" button twice - LED indicator
light will blink slowly.
3. Enter the Default Access Code "1", "2", "3", "4", enter the
new radio code, then press the "RADIO LEARN" button - the
light will turn off.
4. If code is entered incorrectly, the light will blink quickly.

9 Dip Switches

1. Follow the same instructions for openers with 10 dip
switches. Because there are only 9 switches, the Codekey will
read the 10th digital code as OFF, so no programming of this
switch is necessary.

Code Wires

1. Note the numbers of each unclipped code wire. This is the
"Radio Code".See Figure D.
2. Press the "RADIO LEARN" button twice - LED indicator
light will blink slowly.
800-393-9976
