Archer VR2K Installation Operation & Maintenance

Archer VR2K Installation Operation & Maintenance

High volume vacuum regulator

Advertisement

Quick Links

High Volume Vacuum Regulator
General:
The Archer Instruments Model VR2K vacuum regulator is designed for use in
vacuum gas feed systems. The VR2K can be provided with or without an integral pressure
gage.
Safety:
When working with chlorine, always use caution and follow applicable safety
procedures. General safety considerations:
* Store chlorine separately from ammonia.
* When using chlorine, avoid locations that expose the chlorine containers and feed
equipment to direct sunlight.
* Do not apply heater or heat source directly to chlorine containers.
* Ton Containers: Use appropriate handling equipment when moving ton containers. When
readying ton container for use, ensure valves are aligned vertically. The top valve accesses
gaseous chlorine and the bottom valve accesses liquid chlorine. The bottom valve should
never be touched unless your system employs a chlorine heat exchanger (evaporator)
designed expressly for use with liquid chlorine.
Archer Instruments, LLC
Model VR2K
Installation, Operation & Maintenance
www.archerinstruments.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the VR2K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Archer VR2K

  • Page 1 Installation, Operation & Maintenance General: The Archer Instruments Model VR2K vacuum regulator is designed for use in vacuum gas feed systems. The VR2K can be provided with or without an integral pressure gage. Safety: When working with chlorine, always use caution and follow applicable safety procedures.
  • Page 2 Installing the Model VR2K: *IMPORTANT SAFETY NOTES: - The VR2K inlet assembly is connected to the back of the vacuum regulator by means of a lead gasket seal (lead gasket part# LGA-3) and four (4) socket head cap screws. Prior to use and during any periods of significant change in ambient temperature, these screws should be checked to make sure they are tight.
  • Page 3 NOTE: Vent tubing should always be connected and run to a safe location (outside of any building). A vent screen (provided with every Archer Instruments vacuum regulator) should be fitted over the end of vent tubing to prevent insects from entering.
  • Page 4 VR2K, gas feed will begin when the ejector is put into operation. NOTE: If the gas supply to the VR2K is exhausted, the guide pin will retract into the front body. This indicates that gas is no longer flowing and that increased internal vacuum has caused the diaphragm to fully open the inlet valve.
  • Page 5 9) When reassembling, new o-rings should be given a thin film of the Fluorolube grease. SAFETY NOTE: The inlet valve assembly is a critical component of the VR2K. Improper handling or reassembly can result in dangerous leakage of chlorine gas. Archer Instruments recommends that only trained personnel or those familiar with vacuum regulator maintenance service the VR2K.
  • Page 6 HTA-111 Drip Leg Heater SPA-639 Inlet Spring LGA-3 Lead Gasket -inside pressure union Notes: Date: Nov 2019 1. Vacuum Connection is 1” PVC Sch. 80 Socket Union Drawing #: VR2K 2. Vent Tubing is ½” O.D. Archer Instruments, LLC www.archerinstruments.com...
