- Page 1 CYCLIQ.COM USER GUIDE MODEL: CE122...
- Page 2 We love being part of the global cycling community and hope to improve the safety of everyone on the road. We’re active on social media and if you use Strava, we welcome you to join the Cycliq Strava club and ride with our members from around the world ...
-
Page 3: Table Of Contents
Using your Fly12 Audio settings Before your first ride Volume levels Turning on your Fly12 Audible alerts Turning off your Fly12 Airplane mode Light modes Master Reset Video segment length Visual and audio alerts Fly12 CE122 User Guide | 3 of 31... -
Page 4: What's In The Box
1 x M5 screw for Universal Adapter 1 x USB to USB-C cable 1 x Safety Tether 1 x MicroSD Card 1 x Safety information and warranty sheet (not pictured) 1 x Quick Start Guide (not pictured) Fly12 CE122 User Guide | 4 of 31... -
Page 5: Read This Before Using Your Fly12
• Do not look directly at the LED lights when operating. Please note that Cycliq, its subsidiaries and affiliates, and its distributors are • Do not immerse the Fly12 in water or any other liquid. -
Page 6: Your Fly12
Your Fly12 Register your Fly12 We strongly advise that you register the Fly12 with Cycliq. Once registered, you’ll receive notifications for new software and firmware updates, new features, and user tips. Registration also speeds up the process should you require assistance with technical support or warranty queries. -
Page 7: Getting To Know The Fly12
Side (port door closed) Buttons Cycliq 1/8th Turn Mount Microphone Master Reset Button Charge indicator LED Speaker Micro SD Slot Charge Port Tether Slot Back Side (port door open) 1/8th Turn Mount Fly12 CE122 User Guide | 7 of 31... -
Page 8: Setting Up Your Fly12
USB at 2.1A (not supplied) vs computer USB (at as little as 0.5A). Battery life will diminish over time and charge cycles. 3 long high pitched beeps = Less than 12% charged Fly12 CE122 User Guide | 8 of 31... -
Page 9: Inserting And Removing The Microsd Card
Fly12 operates at peak performance and guarantee your ride is always recorded. If you need support with formatting your microSD card, visit our How to format your microSD card page on cycliq.com. microSD card Fly12 CE122 User Guide |... -
Page 10: Mounting Your Fly12 To Your Bike
The Fly12 comes with a Handlebar Mount and a Universal Adaptor 1. On the back of the Fly12 there are two slots for the Safety Tether that feature the Cycliq 1/8th turn quick release system. to be attached through. 2. Thread the thinner part of the tether through the slots, then thread the other end through the loop to secure the tether. -
Page 11: Changing Your Fly12 Settings
It is accessible on your PC or Mac when you plug the Fly12 Q Button into your computer using the supplied USB cable. Alternatively insert the microSD card into your computer’s microSD card reader. Fly12 CE122 User Guide | 11 of 31... -
Page 12: Using Your Fly12
Power level ‘beeps’ will sound, indicating the battery status - see section with the previously used light mode and intensity. Consider bicycle light on Battery Level Indicators on page 8. regulations in your area when setting your light modes. Fly12 CE122 User Guide | 12 of 31... -
Page 13: Visual And Audio Alerts
(refer to charge level) Audible sound: 3, 5 or 10 minute Beeps To listen to tones described in the table above visit the Visual and Audio Alerts Guide for Fly12 CE on cycliq.com. Fly12 CE122 User Guide | 13 of 31... -
Page 14: Features
1920x1080 16:9 1080p Full HDR 1920x1080 16:9 720 HD 1280x720 16:9 Note The resolution of the recorded video can be adjusted via the CycliqPlus mobile app or via your PC or Mac. Fly12 CE122 User Guide | 14 of 31... -
Page 15: High Dynamic Range (Hdr)
This allows the Fly12 to record smoother video in greater detail (please note this feature is not available in HDR mode). Note Electronic Image Stabilisation can be toggled on/off via the CycliqPlus mobile app or via your PC or Mac. Fly12 CE122 User Guide | 15 of 31... -
Page 16: Looping Function
Note A compatible Class 10 microSD card is required for this device see microSD Card Compatibility on cycliq.com. Fly12 CE122 User Guide | 16 of 31... -
Page 17: Manual Footage Capture
Note The Incident protection function can be turned off via the CycliqPlus mobile app or via your PC or Mac, however this is not recommended. Fly12 CE122 User Guide | 17 of 31... -
Page 18: Capturing Still Images
Your safety is our number one priority. When the battery is running low, the Fly12 will manage the available battery capacity by automatically dimming Cycliq recommends carefully familiarising yourself with this function before the strength of the bike light and turning off the camera. -
Page 19: Dashcam Mode
The Fly12 has a stereo microphone which records sound in high quality. It also has a speaker which is used for audible alarms and alerts. Volume levels The volume of the speaker can be set from Off to Level 5. Fly12 CE122 User Guide | 19 of 31... -
Page 20: Master Reset
Video segment length can be changed via the CycliqPlus app. Warning DO NOT complete a Master Reset when the unit is in the process of completing a firmware update as this may damage your Fly12. Fly12 CE122 User Guide | 20 of 31... -
Page 21: Incident Protection Activation
Incident Protection Activation Incident Protection Function 5-minute segment, Incident Protection The following diagrams show what happens when the Incident Protection function is activated. 10-minute segment, Incident Protection 15-minute segment, Incident Protection Fly12 CE122 User Guide | 21 of 31... -
Page 22: Using Your Footage
You can view and edit your footage using the CycliqPlus desktop app you can also overlay Strava metrics and share highlights from your ride. Go to cycliq.com/software to download CycliqPlus desktop for macOS or Windows After your ride, you can access your footage in two ways: 1. -
Page 23: Cycliqplus Mobile App
CycliqPlus mobile app. The resolution of the video that the Fly12 records can be adjusted using these settings. Note You can also manually input the date and time via the CycliqPlus desktop app. Fly12 CE122 User Guide | 23 of 31... - Page 24 Video Logo Timestamp Display This feature can be toggled on and off by using this button. Note Timestamp display is an important feature should you require the footage for legal purposes. Fly12 CE122 User Guide | 24 of 31...
-
Page 25: Updating Your Firmware
The Fly12 firmware will be updated automatically to the latest version and future firmware updates will be just as hassle-free! Visit our CycliqPlus Firmware Updater download page on cycliq.com Fly12 CE122 User Guide | 25 of 31... -
Page 26: Troubleshooting Your Fly12
DO NOT reboot your Fly12 when in the process of completing a firmware update as this may damage the device. Still need help? Go to Fly12 Help Page on cycliq.com where you can view help topics and contact our friendly support team for help in troubleshooting any issues you may be having. -
Page 27: Technical Data
Power Source Rechargeable Lithium Ion Battery Battery Size 4200mAh (approx. 8 hours in camera only mode) Watt Hours 15.96wh Voltage 3.7v Ingress Protection IP67 Operating Temperature/Humidity 0-45°C (32–113°F) Storage Temperature/Humidity 0-45°C (32–113°F) Fly12 CE122 User Guide | 27 of 31... -
Page 28: Compliance Statements
• Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Fly12 CE122 User Guide | 28 of 31... - Page 29 FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications Fly12 CE122 User Guide | 29 of 31...
-
Page 30: Regulatory Information
Risk of explosion if battery is replaced by an incorrect type. Cycliq recommends the following: Dispose of used batteries according to the instructions. • Do not look directly at the light. • Do not leave the light on when not in use. Fly12 CE122 User Guide | 30 of 31... - Page 31 CYCLIQ.COM PO Box 404 Subiaco WA 6904 Australia info@cycliq.com Fly12 CE122 User Guide - Version 2021.10 MODEL: CE122 Fly12 CE122 User Guide Cycliq reserves the right, at its discretion, to change and modify portions of this User Guide.
