- Page 1 Owner’s Operation Manual SM-S112TL Alkaline Water Ionizer Warning: Incorrect installation and/or operation could void your valuable warranty READ THIS Please protect your investment! MANUAL CAREFULLY...
-
Page 2: Table Of Contents
Table of contents SM-H112TL Safety Precautions 03/04 Names And Functions 05/06 How to Use 07/12 Replacing Your Filter 13/14 Composition of Filter How to measure pH Counter Top Installation Instructions Installation Instructions 18/20 Trouble Shooting Guide 21/22 Product Specifications IO-600U Name and functions of parts 24/25 Accessories... -
Page 3: Safety Precautions
Safety precautions Read the recommendations below before installing the ionizer DO NOT MAKE A REPAIR YOURSELF! Attempting to do so will VOID your warranty! Contact service center if the machine breaks down. If your machine becomes submerged in water, unplug the power cord from the wall before removing your machine from the water. - Page 4 Within 1M, do not use the outlet hose to be longer than 1M If the appliance makes strange or unusual noises.If burning smells are detected, unplug the power cord immediately and contact customer service A / S DO NOT close, bend, pinch, press or otherwise obstruct output ports or hoses. pH reagent liquid precautions DO NOT expose the pH measuring reagent to extreme heat, flames or fire.
-
Page 5: Names And Functions
Names and functions Front Function display panel Function button Flexible stainless Body steel alkaline water outlet. Rear Filter Cover Power switch Fuse holder Acidic water Water supplying hole discharging hole A/C power cord... - Page 6 Indicators / Controls Displaying filter lifespan Indicating total amount of filter use Filter Running Time 3888 00:00:14 Displaying water discharging time Indicating time during which water is discharged Alkaline2 Displaying number of grade in use Indicating number of grade in alkaline/acid and purification currently in use Flow 9 .0...
-
Page 7: How To Use
How to use Initial operation Power up your ionizer. Turn on power switch on back side after plugging power code into socket. Signal sounds, initial screen appears and disappear again which makes it stand-by status. Start water flow through your ionizer. - Press the "POWER"... - Page 8 When drinking alkaline water Repeat steps 1-3 above, or with water already running through the machine then: When pressing "ALKALINE " water selection Filter Running Time 3888 button, graphic lamp is on which 00:00:14 indicates character of alkaline water, Alkaline2 number of grade, and announcement can be heard which informs Flow...
- Page 9 When using acidic water ※This function is necessary when getting a lot of acidic water and using it for washing face or body. Repeat steps 1-3 above, or with water already running through the machine then: When pressing "ACIDIC" water selection Filter Running Time 3888...
- Page 10 When drinking purified water Repeat steps 1-3 above, or with water already running through the machine then: When pressing "FILTERED" water selection button, graphic lamp is on which indicates character of filtered water, number of grade, and announcement can be heard which informs filtered water grade. Filter Running Time 3888...
- Page 11 Volume adjusting function for voice information Press "VOICE" button for 3 to 5 seconds under stand-by mode. Adjust volume by alkaline and acidic button. Volume consists of 0 to 10 steps. SAVE : VOICE UP : ALKALINE EXIT : FILTER DN : ACIDIC Stand-by mode status If saving volume by pressing "VOICE"...
- Page 12 Time and date adjusting function After entering time setting "MODE" screen by pressing setting button among stand-by mode, select year, month, date, hour and minute by setting button and adjust them by alkaline button and acidic button respectively. Time Setting Year 2013 NEXT : VOICE...
-
Page 13: Replacing Your Filter
Replacing Your Filter How to replace the filter IMPORTANT! Stop operating product before replacing the filter When lifespan of filter comes to an end, graphic figure of filter indicates 0000 and filter change icon flickers, which is informing that it’s time to change filter. Stop supplying water by turning power switch on back side of product to OFF position. - Page 14 Insert the new filter into the compartment. Remove the plastic caps covering both ends of the new filter. Seat the large opening on the bottom of the filter cartridge onto the base in the center of the filter cushion. Push the filter down and into the housing compartment ensuring the opening at the top of the filter is seated properly into the fitting at the top of the housing.
-
Page 15: Composition Of Filter
Composition of Filter High Performance NSF Filter High Performance NUF Filter (Option) Fiber Filter Silver Activated Carbon Fiber Filter Activated Carbon Fiber Filter Calcium Fiber Filter Fiber Filter Activated Carbon Activated Carbon Fiber Filter Fiber Filter Calcium Calcium Fiber Filter Tourmaline Tourmaline Fiber Filter... -
Page 16: How To Measure Ph
How to measure pH IMPORTANT! Water quality and mineral content vary greatly in different Iocations and will directly impact machine performance with respect to pH and hydrogen production. Fill the three test containers provided about 1/2 full with alkaline, acidic, and H water each. -
Page 17: Counter Top Installation Instructions
Counter Top Installation Instructions Connecting to a Standard Faucet Diverter Valve Source Water Dust Pre-Filter Inlet Outlet Make sure the arrow on the WARNING! dust pre-filter is pointing the same direction as the water flow. Connecting to a Cold Water Valve Make sure the arrow on the WARNING! dust pre-filter is pointing... -
Page 18: Installation Instructions
Installation Instructions Installation: Connecting to a Standard Faucet CAUTION Before installing, shut off water supply. [Figure 2] [Figure 1] Diverter PE Hose Diverter Valve Remove aerator from faucet. Attach Connect 1/4 in.(PE) hose to the diverter valve. Use sizing rings and diverter in "Figure 2". - Page 19 Installation: Connecting to a Cold Water Valve CAUTION Before installing, shut off water supply. [Figure 1] PE Hose [Figure 2] T-adapter Cold Water Valve Loosen the nut of the cold water Connect 1/4 in.(PE) hose to the valve. T-adapter in "Figure 2" [Figure 3] [Figure 4] inlet...
- Page 20 CAUTION Acidic water tubing must not be raised do not use the outlet hose Within 1M, higher than the base of the product. to be longer than 1M CAUTION When using a Reverse Osmosis filter prior to the machine, you will need to verify the R,O.
-
Page 21: Trouble Shooting Guide
Trouble Shooting Guide Abnormal condition Cause(s) Resolution The Function Display A power plug is not properly Properly insert power plug into Panel does not come on. inserted, or it is inserted into a a correctly functioning power faulty outlet. outlet The fuse is blown. - Page 22 Abnormal condition Cause(s) Resolution The Function Display Panel / Faulty PCB Immediately unplug the unit display indicators do not (Printed Circuit Board) and contact Customer Svc. come on even after turning arrange service. the tap on. Strange smell from Expired filter from ordinary use Replace your filter.
-
Page 23: Product Specifications
Product Specifications Product Manufacture Permission Number No. 610 by KFDA (Korea Food & Drug Administration) Feature Ion Water Generator Model SM-S112TL INPUT Voltage AC 120V or 240V, 50Hz~60Hz Power Supply TRANS(5P) , SMPS( 5/7P/9P) Power Consumption SMPS(250W ) Overall Dimension 270 x 383 x 135 (WxHxD) mm Applicable Water Inflow Pressure 0.7~5kgf/㎠... -
Page 24: Name And Functions Of Parts
Name and functions of parts Faucet Function display panel Alkaline Water Outlet Acidic Water Outlet Body... - Page 25 Display Filter life Flow indicator Home button Alkaline water button Selection indicator Acidic water button Filtered button Selection button Setting button Power button Alkaline Acidic Filtered...
-
Page 26: Accessories (Needed For Faucet Installation)
Accessories (Needed for faucet installation) CAUTION Product Requirement : Water pressure should be maintained at a constant rate, when the water pressure is too low, water cannot flow through the unit. Accessories Faucet Large Alkaline Small Acidic Alkaline Water Water Fitting Water Fitting Outlet Adapter Allen wrench... -
Page 27: How To Install The Faucet
How to install the faucet Accessories (Needed for faucet installation) To connect the faucet All the fittings are push in style fittings. To attach the hoses to any fitting, firmly insert the end of the hose into the fitting. Pull firmly to check to connection - you should not be able to pull the hose out. - Page 28 Harness Alkaline Water Diverter Power Cord Acidic Water Place the Ionizer in an appropriate place under your sink. Connect the 1/4inch Acidic Water Hose to the small fitting on the Acidic Hose extending from the faucet to Acidic Water Outlet on the Ionizer. Pull firmly to check to connection You should not be able to pull the hose out.
- Page 29 Join the wire from the faucet to the Connect Wire(Harness). Plug the Connector Cord into the Connector Port on the top of the ionizer. Connect the power cord into an appropriate outlet. Make sure the outlet you plug your ionizer into is always live You must use a nonswitched outlet under the sink where you are installing the ionizer.
-
Page 30: How To Use
How to use To select Alkaline water With the water running through your faucet then: Press the "ALKALINE" button to select the desired setting from 1 - 4. The alkaline water will come out from the top spout. NOTE Your ionizer will always "remember" the last setting used. If the previous selection was Alkaline Level 1, when you start flow through the ionizer next time you use the ionizer it will automatically process at Alkaline Level 1. - Page 31 To select Acidic water NOTE Acidic water is used except for drinking. DO NOT DRINK With the water running through your faucet then: Press the "ACIDIC" button to select the desired setting from 1 - 4. The acidic water will come out from the top spout. NOTE Your ionizer will always "remember"...
- Page 32 To select Filtered Only water With the water running through your faucet, press the “Filtered Only” button. The display panel will show a green symbol. The Filtered water will come out of the top spout. Filtered Water Filtered How to shut off the water flow from your ionizer With the water running through your faucet then depress the home button.
- Page 33 Volime<0> Volime<1> Volime<2> Volime<3> Volime<4>...
-
Page 34: Product Specifications
IO-600U Model 380W SMPS Power Supply Max 150W or 250W Power Consumption 62 x 247 x 255 (W x H x D)mm Dimension 9 plate Electrode Alkaline (4 Level), Purified Water, Acidic Water (4 Level) Electrolysis Setting Cleaning Double Automatic Reverse Cleaning System (DARC/ PATENTS ) pH4.0(±0.5)~11(±0.5) pH Value 2.8"... -
Page 35: Warranty Card
WARRANTY CARD 1.Warranty Detail 1.Warranty Detail This product passed the precise inspection under strict quality control. In case the product is found to have any defect in production or to get any spontaneous mechanical malfunction within the warranty term,return the unit to our sales agency, distributor or our service center along with this warranty card for repair free of charge. - Page 36 SM-S112TL Alkaline Water Ionizer...
