RITE-HITE Corporation does not recommend any particular lockout device, but recommends the utilization ® of a device that meets OSHA standards (refer to OSHA regulation 1910.147). RITE-HITE Corporation also ® recommends the review and implementation of an entire safety program for the Control of Hazardous Energy (Lockout/Tagout).
GUARDRITE FLEX ® TOOLS AND COMPONENTS Unpack all of the components and compare to the part breakout in the back of this installation manual. Notify the factory if parts are missing or damaged. TOOLS REQUIRED: Hammer drill with ½" x 6" long concrete bit Impact wrench with 9/16"...
GUARDRITE FLEX ® INSTRUCTIONS ATTACHMENT OF THE RAIL GUIDES TO THE COLUMNS (7") NOTI E Over-tightening the screws may make the rail guide too tight and the rail hard to insert. Determine the desired rail mounting heights. Rails can be positioned at any height but, standard mounting heights for the (2) rail system are 42"...
Page 6
GUARDRITE FLEX ® ATTACHMENT OF THE RAIL GUIDES NOTI E TO THE COLUMNS (43") Over-tightening the screws may make the rail guide too tight and the rail hard to insert. Position the rail guide in the desired location Repeat this process for other columns, or to on the column paying attention to the attach more than one guide to a column for orientation with the base plate.
Page 7
GUARDRITE FLEX ® ANCHORING INSTALLATION OF COLUMN CAP Anchor the columns to the floor with the (2) ½" Press the plastic cap provided into the top of x 5.25" concrete anchors that are provided. If the column. possible, mount them on opposite corners of the base plate.
