- Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL Nozzle and Silencer...
-
Page 2: Safety Warnings
SAFETY WARNINGS MANUAL CONTENTS Safety Warnings General Information Installation Operation Service Troubleshooting WARNING Do not attempt to operate this equipment without first reading and understanding the manual enclosed with this device. Suitability for use of this device lies solely with user. Fill in your model and serial number in the blank spaces below. - Page 3 If there is any portion of this manual or function you do not understand, contact BlastOne International to obtain further assistance. Keep this manual available for reference. WARNING Safety alert symbol.
- Page 4 It may also be used to alert against unsafe practices. DANGER Abrasive blasting exposes operators and bystanders to hazards that can cause injury or death. The operator of the SnakeBite XQ Nozzle and Silencer must: • always comply with local laws, regulatory requirements and codes of practice when using the SnakeBite XQ Nozzle or Silencer.
- Page 5 PPE when blasting operations are in progress. CAUTION Operator Complacency: the noise and thrust generated by the SnakeBite XQ Nozzle and Silencer when operated with the silencer is significantly lower than other typical blasting nozzles. Operators and bystanders should be aware of these...
-
Page 6: General Information
The SnakeBite XQ Nozzle and Silencer represents a step change in abrasive blasting nozzle design and functionality. The unique internal nozzle geometry of the SnakeBite XQ Nozzle produces a more stable blast stream than conventional nozzles. This results in less blast stream turbulence, improved... -
Page 7: Installation
If the Nozzle or Silencer is damaged, cease using the damaged product. Installing the Nozzle The SnakeBite XQ Nozzle is available in a range of standard nozzle sizes and includes a standard contractor inlet thread. Inspect the condition of the nozzle liner and jacket prior to installing it into the nozzle holder. - Page 8 INSTALLATION The nozzle is installed onto the blast hose by screwing the bell shaped inlet end of the of the nozzle into the nozzle holder. Make sure the nozzle washer is located as shown below. Continue to screw the nozzle into the nozzle holder until the nozzle reaches the end of the nozzle holder thread, then tighten the nozzle until it is hand tight.
- Page 9 INSTALLATION Installing the Silencer Inspect the condition of the silencer liner and jacket prior to installing it onto the nozzle. Make sure the silencer liner is not damaged or cracked or has pieces missing. Inspect the silencer liner wall thickness at the exit of the silencer – typically the silencing effect will reduce if the silencer is excessively worn.
- Page 10 WASHER NOZZLE HOLDER NOZZLE AND SILENCER INSTALLATION ARRANGEMENT UNLESS OTHERWISE SPECIFIED: DEBURR AND DO NOT SCALE DRAWING REVISION BREAK SHARP EDGES DIMENSIONS ARE IN MILLIMETERS BLASTONE INTERNATIONA SURFACE FINISH: NAME SIGNATURE DATE TITLE: #6 Assembly DRAWN TREVOR SEEWALD CHK'D TOLERANCES: APPV'D LINEAR: ±...
-
Page 11: Operation
Nozzle and Silencer Care: Take care to place down the SnakeBite XQ nozzle and silencer rather than dropping from height and to avoid impact with hard surfaces as this may damage the nozzle and silencer. - Page 12 2” bull hose coupled to an adequately sized compressor for the nozzle size used – see BlastOne catalogue for compressor sizing. The SnakeBite XQ has been designed to optimise abrasive blasting using GMA Australian Garnet. Use with alternative abrasive types may result in reduced performance outcomes compared to using GMA Australian Garnet.
- Page 13 OPERATION The optimum nozzle standoff distance will depend on the type of coating to be removed and is influenced by factors such as coating type and thickness, abrasive type being used, worksite access and required surface profile. When safe to do so, start blasting at a stand-off distance of 500-600mm (20-24 in).
- Page 14 The SnakeBite XQ Nozzle and Silencer are available in industry standard nozzle sizes: SNAKEBITE XQ PART NO. Nozzle &...
-
Page 15: Troubleshooting
TROUBLESHOOTING POSSIBLE CAUSE POSSIBLE SOLUTION Low operating Adjust nozzle outlet pressure pressure to 100psi. Adjust abrasive flow rate to the Low cleaning In appropriate recommended flow rate. abrasive flow rate rate for the nozzle size and abrasive type combination. Damaged or worn Replace the damaged nozzle liner or worn component. - Page 16 Toll Free 800 999 1881 Email sales@blastone.com www.BlastOne.com NORTH AMERICAN OFFICES Chicago Columbus Minneapolis Los Angeles MALAYSIA B-05-07 Neo Damansara, Jalan PJU 8/1, Bandar Damansara Perdana, 47820 Petaling Jaya, Selangor, Malaysia Tel 03 7725 0371 Email sales.my@blastone.com www.BlastOne.my © BlastOne 2021 B3962...
