Summary of Contents for Datapath ALIGO QTX100
- Page 1 Connection Quick Start Guide Aligo QTX100 Aligo RX100 Engineering the world’s best visual solutions...
- Page 2 Aligo Quick Start Guide Aligo Quick Start Guide OPTIONAL ACCESSORIES STEP 1 CONNECTING THE ALIGO QTX100 AND RX100 Thank you for purchasing the Datapath Aligo QTX100 or RX100 units. The aim of (PURCHASED SEPARATELY) this document is to quickly guide you...
- Page 3 MADE IN ENGLAND the rear of the Aligo QTX100. Note: Where only one input is required, then input 1 must be used INPUTS first before using inputs 2-4. Input 1 must always be connected to a valid HDMI source in order to...
- Page 4 (TX) / received from the network and output to HDMI sink (RX). ALIGO QTX100 FRONT PANEL The Aligo QTX100 and Aligo RX100 have LEDs on the 10G ports to indicate that each 10G Ports network channel has good stable power.
- Page 5 Also ensure that all Aligo devices are on the same Local Area Network (LAN/VLAN) as the Aetria Network Manager server. This will have been pre-configured by Datapath and should be connected, powered up and running before going any further.
- Page 6 Whilst every effort is made to ensure that the information contained in this Quick Start Guide is correct, 2014/35/EU and 2011/65/EU. Datapath Limited make no representations or warranties with respect to the contents thereof, and do not accept liability for any errors or omissions.
- Page 7 Datapath UK and Corporate Headquarters Bemrose House, Bemrose Park, Wayzgoose Drive, Derby, DE21 6XQ, United Kingdom +44 (0) 1332 294 441 sales-uk@datapath.co.uk Datapath North America 2490 General Armistead Avenue, Suite 102, Norristown, PA 19403, USA +1 484 679 1553 sales-us@datapath.co.uk...
