RC11x0DK-RC232 Quick Start
Quick Start Guide
1. Set up each board as illustrated in the picture
Connect to
power
Connect to
serial port
2. Download the latest version of RCTools-RC232 from www.radiocrafts.com and install
as described in the RCTools Installation Guide.
©2008 Radiocrafts AS
RC11x0DK-RC232
RC11x0DK-RC232 Quick Start (rev. 1.0)
Ensure that the
power jumper is
mounted
Connect the
antenna
Ensure that RXD
and TXD jumper
are mounted
Page 1 of 2
