Measure straight line function
Measure dot percentage
icon
Remark: Please start measuring after the image is still.
Click the icon to start measuring straight line. It shows the function of measuring
distance from point to point. Randomly choose two points on the screen, it shows a straight
line plotted by the two points. On the bottom left corner will show the length of this straight
line in mm or μm. Red cross endpoint may use those arrows shown on the bottom right corner
to do fine movement. The bidirectional icon in the middle
endpoint to do fine location adjustment.
Add number of net line icon
can change the
