- Page 1 ExitOxy User manual Type Usermanual Date 22-05-2019 Version / Revision Versie 2.2, Revisie 00 Status Accepted Company PRESSCON Location Honselersdijk...
-
Page 2: Table Of Contents
Table of Contents Introduction ..................................3 Description of the hazard symbols ............................3 System overview ................................ 4 Surface ..................................5 Water-side connection ..............................5 Elektrical connection ..............................6 Commissioning ................................7 Operation ..................................8 First use ..................................8 Malfunction ................................. 9 Maintenance ................................ -
Page 3: Introduction
Foremost we congratulate you on your purchase of a PRESSCON ExitOxy degasser system. This manual describes how to install a PRESSCON ExitOxy degasser system. If there, despite our explanation in this manual, is a lack of clarity with regard to the installation or if there are any questions in another way, don’t hesitate to contact us through the information below. -
Page 4: System Overview
System overview Air vent Level sensor stop Vacuum-overpressure manometer Degassing tank Level sensor start Level sensor minimal Disk valve Ball valve Control cabinet 10. Centrifugal pomp 11. Supply terminal “Inlet” 12. Retour terminal “Outlet” Dirt trap Figure 1. System overview Page 4 of 12... -
Page 5: Surface
40°C which benefits the life span of the machine. If the water temperature is higher than 40°C it is possible that this is detrimental to the life span. In this case it is advised to install the ExitOxy together with PRESSCON or a licensed installer. -
Page 6: Elektrical Connection
Before the ExitOxy can be supplied, the following points must be checked: Is there a correct main power cable supplied? The ExitOxy is delivered without its own power cable. It is therefore desirable the an authorized electrician provides a correct main power supply cable to the location of the ExitOxy. -
Page 7: Commissioning
Figure 7. ExitOxy back view When the ExitOxy is delivered it is already tested and adjusted. The ExitOxy is adjusted by adjusting the disc valves properly. The disc valves as in Figure 7. No. 2 are therefore sealed when the system is delivered. The disc valve on the inlet connection has to be newly adjusted since the water pressure of the system is different on every location. -
Page 8: Operation
First use The ExitOxy can be put on mode 1 (manual) in the first week. The ExitOxy will degas most of the water in its first week in this way. After a week can the ExitOxy be put on mode 2 (automatic on). -
Page 9: Malfunction
Malfunction The ExitOxy is designed as a quality and a trustworthy product. It can however, not be ruled out that the ExitOxy can get defect. When this happens, a malfunction in the operational process of the machine is created. In that case the machine will let the user know. -
Page 10: Waranty
Waranty PRESSCON offers a warranty on the components of the ExitOxy for 1 year, in the assumption that the following conditions are met: • The equipment is installed by PRESSCON or under direct or indirect supervision of PRESSCON; • The equipment is undamaged and unprocessed and is not defect as a result of improper use;... -
Page 11: Technical Data
Noise level [dB(A)] Allowed stance The ExitOxy only functions in a straight standing stance. The ExitOxy is securely attached to the local pipe network and can therefore not move after mounting. The ExitOxy can however still function properly when it is turned over the yaw-axis or slightly tilted over de roll-axis or the pitch-axis. -
Page 12: Appendix
This manual has been written in order to support the mechanic, installer or customer in adjusting, modifying or working with a product of PRESSCON. Its aim is to maintain and possibly improve the quality of its products. If additional information or support is requested then PRESSCON can be consulted through the following information.
