Ordering Information - Logix TC-2000 Operation And Installation Manual

TC-2000 Specifications
Model TC-2000-120/240:
Model TC-2000-24:
Resistive/GP Amps:
Full-Load Amps:
Lock Rotor Amps:
Horsepower:
Pilot Duty:
Operating Ambient Temperature
Storage Temperature
Hosedown
ETL Listed
Standard Conformance

Ordering Information

TC-2000 Model
TC-2000-120/240
TC-2000-120/240-2
TC-2000-24
TC-2000-24-2
Copyright © 2006 Logix ®. All Rights Reserved. Logix is a Registered Trademark of The Controls Group Inc. Kirkland, WA USA
The information contained in this document is subject to change without notice. Logix makes no warranty of any kind with regard
to this document, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Further, Logix assumes no responsibility for any errors which may occur in this document. No part of this document may be
copied or reproduced in any form, without the prior written permission of Logix. This document was printed in the USA.
115/220VAC ±15% 50/60Hz 10 VA Max. Fuse F1: 0.1 Amp Fast-Acting 250VAC 5x20mm,
Wickmann 193-0100 or equal.
24VAC ±15% 50/60Hz 10 VA Max. Fuse F1: 0.5 Amp 250VAC Fast-Acting 5x20mm, Wickmann
193-0500 or equal.
Stage 1 & 2 Output SPDT Relay Ratings
115VAC 208/220VAC
N.O. N.C. N.O.
10.0 6.0 5.0
9.8 5.8 4.9
58.8 34.8 29.4
½ HP 1/3 HP ½ HP
125VA 125VA 125VA
-4 F to +122 F (-20 C to +50 C)
-40 F to +176 F (-40 C to +80 C)
Listed Type 4X, meets and passed UL Standard 50, section 35 hosedown test.
Regulatory Safety Approvals
File Number 3028665
UL Standard 508 for Industrial Control Panels, Canadian CSA Standard C22.2 No14-95. UL
Standard 50 for Type 4X Enclosure. Each unit HiPot tested to 1,700 Volts AC.
Description
120VAC or 208/240VAC Controller Power. Single Temperature Probe.
120VAC or 208/240VAC Controller Power. Dual Temperature Probes.
24VAC Controller Power. Single Temperature Probe.
24VAC Controller Power. Dual Temperature Probes.
Warranty and Copyright Information
Logix® TC-2000 Process Controller, Page 7 of 7
Power Requirements
24VAC
N.C. N.O.
3.0 10.0
2.9
17.4
1/4 HP
125VA 125VA 125VA
Environmental
Fuse F2 and F3: 10 Amp Time-Delay
250VAC 5x20mm, Wickmann 181-2100
N.C.
or equal
6.0
