Safety Notification
It is very important for the user to consider the adverse effects of power, wiring, component, sensor, or software failures in
designing any type of control or monitoring system. This TC-2000 Process Controller is not designed for applications in which
a malfunction of the Process Controller could result in a hazardous and or dangerous condition. In no circumstance may this
Process Controller be used to limit any piece of equipment to a safe mode of operation. This is especially important where
economic loss or human life is involved. It is important that the user employ satisfactory overall system design. It is agreed
between the buyer and Logix that this is the buyer's responsibility. It is the responsibility of the installer to ensure that the
installation is in compliance with all national and local codes. Installation should only be attempted by a licensed electrician
familiar with codes, standards, and proper safety procedures for line-voltage installations.
Caution:
Document Prior to Installation and
Operation of this Unit.
TC-2000 Process Controller Description
The TC-2000 Process Controller is a rugged two-stage On/Off process controller featuring data communications monitoring,
control and access with a Logix® Industrial Control System or monitoring and setpoint access with a standard PC. The unit is
housed in a water-tight Type 4X rated enclosure suitable for washdown and outdoor locations. Additional features include
independently adjustable setpoints and separate relay outputs. Each stage is configurable for operation in the Cooling or Heating
mode. High and Low temperature alarms providing a visual warning (flashing display) if the process temperature exceeds either
of the alarm setpoints. Additionally, the second relay output can be configured as an alarm output allowing direct control of an
external alarm horn or beacon. The controller comes complete with a reliable highly accurate solid-state temperature sensor
encased in a stainless-steel probe with eight feet of cable. An optional second temperature sensor is available which allows split
temperature monitoring and control. Also, a user field "scratchpad" setpoint is provided allowing computer access to field entered
information (e.g. specific gravity).
Button Functions
On/Off button - used to activate and deactivate the controller. When deactivated, the controller enters the standby
On
mode and both output relays are de-energized but power is not removed from the controller.
Off
Arrow buttons - used to adjust setpoints and other operating parameters when configuring the controller.
During normal operation, pressing and holding the
(Stage 1 LED will also illuminate). Pressing and holding the
control Setpoint (Stage 2 LED will also illuminate). Pressing and holding both the
buttons will display the second temperature (for Dual sensor controllers only).
Set button - used to access configuration setpoints and other operating parameters. This button can be locked out.
Set
Refer to Locking the Set Button below.
Display Functions
Temperature Display - displays actual temperatures during normal operation. While in standby, the message "Stop" is
displayed. During configuration, setpoint temperatures, prompts and parameter values are displayed.
®
Logix TC-2000 Dual Stage Process Controller
Operation and Installation Manual
Important Safety Considerations
Read this Entire
Logix® TC-2000 Process Controller, Page 1 of 7
Warning:
Risk of Electrical Shock. Severe
injury or death can result from electric shock
during contact with line voltage wiring and
equipment. Disconnect and lock-out all power
sources during installation and service.
up arrow button will display the Stage 1 control Setpoint
down arrow button will display the Stage 2
Revised 07/10/2006
