David Round & Son, Inc.
Ruger Products Division
32405 Aurora Road
Cleveland, OH 44139
Phone: 440-248-4700
www.rugerequipment.com
RC1000S
SERIAL NUMBER
O P E R A T O R ' S M A N U A L
All operators must read,
understand, and apply all
safety instructions before
operating this equipment.
IMPROPER USE
OF THIS EQUIPMENT
CAN BE HAZARDOUS!
For safety, one
copy of this manual
must be stored on
the equipment and
referred to by all
operators.
Advertisement
Table of Contents
Related Manuals for Ruger RC1000S
Summary of Contents for Ruger RC1000S
- Page 1 For safety, one David Round & Son, Inc. copy of this manual Ruger Products Division must be stored on 32405 Aurora Road Cleveland, OH 44139 the equipment and Phone: 440-248-4700 referred to by all www.rugerequipment.com operators. RC1000S SERIAL NUMBER O P E R A T O R ’ S M A N U A L...
- Page 2 Phone: 440-248-4700 Fax: 440-248-8544 www.rugerequipment.com E-mail: info@davidround.com Below is a list of standard accessories that you should have received with your RC1000S • Operator’s Manual • Swivel Hook with Safety Latch •...
-
Page 3: Table Of Contents
Insert Sheets ....................4-5 Maintenance Instructions ................. 6 Recommended Parts .................. 7-9 Operational Steps ....................10 Jack Inspection Check List ................. 11 Jack Service Instructions ................12 Lubrication ......................13 Safety Tips for Using Ruger Cranes ..............14 Warranty Information ..................15-17... -
Page 4: General Information
3. All parts are FOB Solon, OH. Terms are Net 30. Minimum order is $50.00. 4. Quality at Ruger starts with raw materials which are inspected to insure our products will be of good quality and free from defects. Each product is tested completely and rechecked before shipment. -
Page 5: Receiving Procedure
RECEIVING PROCEDURES RECEIVING PROCEDURES RECEIVING PROCEDURES RECEIVING PROCEDURES RECEIVING PROCEDURES BEFORE ACCEPTING DELIVERY FROM THE CARRIER In accepting this shipment, the carrier has acknowledged receipt in good condition and complete as shown on the Packing List and/or Bill of Lading. RECEIVING INSPECTION CHECK LIST wheels and casters Check... - Page 6 TION RETURNED GOODS AUTHORIZATION must number be assigned by the Ruger customer service department for approved returns. This must number appear on all accompanying paperwork. There will be a Restocking Charge for all returned purchases. Customized units are not returnable and are non-refundable.
-
Page 7: Insert Sheets
Phenolic casters with roller bearing wheels ANSI/ASME PALD-12C standards. Meets ANSI Z.535 Prices, Specifications, and Options are subject to Change Without Notice. All Ruger products are shipped F.O.B. Solon Ohio 44139 Unit Ships-NMFC #189240 - Class 85 Shipping Wt. 285 lbs FAX: 440-248-8544 E-mail:info@davidround.com... - Page 8 Cleveland, OH 44139 Phone: 440-248-4700 VERSATILE www.rugerequipment.com RELIABLE MODEL: RC1000S Model ..............RC1000S Max. Capacity ............ 1000 lbs Overall Base Length ........... 75” Overall Width ............32 1/2” Overall Height ............78” PUMPING CYCLES Width Between Legs ........... 24 1/2”...
-
Page 9: Maintenance Instructions
MAINTENANCE INSTRUCTIONS MAINTENANCE INSTRUCTIONS NOTE: There is an overload relief valve built into the hydraulic system of every new Ruger Crane. This safety valve is set at the factory, under measured loadings, and opens at about 10% over the rated capacity, preventing the crane from lifting. -
Page 10: Recommended Parts
RECOMMENDED P RECOMMENDED P RECOMMENDED P RECOMMENDED P RECOMMENDED PAR ARTS... - Page 11 RECOMMENDED P RECOMMENDED P RECOMMENDED P RECOMMENDED P RECOMMENDED PAR ARTS COMPLETE JACK ASSEMBLIES: 09-004 AND 09-005 REPAIR KITS PACKING KIT: #768-2 CONSISTS OF ITEMS NO. 2,5,9,28,32 (ALL CRANES) PUMP PISTON KIT: #768-3 CONSISTS OF ITEMS NO. 23,24,25,26 (ALL CRANES) CHECK VALVE KIT: #81053 CONSISTS OF ITEMS NO.
- Page 12 ORDER PARTS BY PART NAME AND NUMBER. BE SURE TO INCLUDE MODEL AND SERIAL NUMBER. All parts are FOB Solon, OH. Terms are /Net 30. Minimum order - $50.00 MODEL ________________________ SERIAL NUMBER ___________________________ RC1000S CRANE MODEL N° WARNING BOOM EXTENSION CAPACITIES-LBS.
-
Page 13: Operational Steps
OPERA OPERA OPERA OPERA OPERATION TION TION TION TIONAL STEPS AL STEPS AL STEPS AL STEPS AL STEPS Operating the Hydraulic Jack To operate the hydraulic jack you need to start by setting the release valve. In order to raise the boom the valve needs to be closed. To close the valve turn the valve knob clockwise (CW) until it stops turning. -
Page 14: Jack Inspection Checklist
JACK INSPECTION CHECKLIST COMPONENTS INSPECT FOR CORRECTIVE ACTION STRAIGHTNESS, SCORE PUMPING PISTON, ITEM MARKS, PITTING, HEAD OR REPLACE IF ANY OF THESE HOLE DEFORMATION, LEAKAGE CONDITIONS ARE FOUND. AROUND PACKING NUT. REPLACE. ALIGNMENT OF PUMP LINKAGE PINS, ITEMS W ORN OR BENT. PISTON IS DEPENDENT ON THESE 16, 19, &... -
Page 15: Jack Service Instructions
JACK SERVICE INSTRUCTIONS If the crane fails to hold or lift its rated load, inspect and repair using the following information. All parts referenced are shown in jack breakdown. Remove jack from crane for all service work. A. Control Valve (Item 30) – Turn jack upside down. Remove valve stem by turning counter-clockwise. -
Page 16: Lubrication
L L L L L UBRICA UBRICA UBRICA TION TION UBRICA UBRICATION TION TION ITEM NO. DESCRIPTION WHEN Boom Pivot Point Chassis Lube Apply Monthly Jack Mount Pivot Point Chassis Lube Apply As Needed Cylinder Ears on Boom Chassis Lube Apply As Needed Load Wheel Axles Chassis Lube... -
Page 17: Safety Tips For Using Ruger Cranes
SAFETY TIPS FOR USING RUGER CRANES SAFETY TIPS FOR USING RUGER CRANES SAFETY TIPS FOR USING RUGER CRANES SAFETY TIPS FOR USING RUGER CRANES SAFETY TIPS FOR USING RUGER CRANES Operator Keep hands and feet clear of crane base and wheels. -
Page 18: Warranty Information
WARRANTY We warrant that our standard products will be of good merchantable quality, free from defects in material and workmanship, and will conform to the characteristics represented by us for: 1 Year On metal frames, castings and weldments 1 Year On hydraulic seals, wiring and hoses. - Page 19 It should be verified that the equipment will do the job for which it was ordered for. If a problem occurs with a Ruger product, the ideal solution will get the equipment back into service promptly with costs of the repair paid by the appropriate party -- either the carrier,...
- Page 20 1. Proceeding with repairs and submission of invoices for factory payment or credit, relying on the fairness of Ruger's service people to back up the customer, the distributor and the equipment to the maximum responsible limit subject to the terms of the warranty itself, or..
