David Round & Son, Inc.
Ruger Products Division
32405 Aurora Road
Cleveland, OH 44139
Phone: 440-248-4700
Fax: 440-248-8544
Email: info@davidround.com
www.rugerindustries.com
RC1000
O P E R A T O R ' S M A N U A L
SERIAL NUMBER
All operators must read,
fully understand,
and apply all safety
instructions, before
operating this equipment.
IMPROPER USE
OF THIS EQUIPMENT
CAN BE HAZARDOUS!
referred to by all
MD1001E2OM
Copyright 1999, Ruger Industries, Inc.
Job# 610/798
For safety, one
copy of this
manual must be
stored on the
equipment and
operators.
Advertisement
Table of Contents
Related Manuals for Ruger RC1000
Summary of Contents for Ruger RC1000
- Page 1 O P E R A T O R ’ S M A N U A L All operators must read, fully understand, and apply all safety instructions, before operating this equipment. IMPROPER USE OF THIS EQUIPMENT CAN BE HAZARDOUS! MD1001E2OM Copyright 1999, Ruger Industries, Inc. Job# 610/798...
- Page 2 If you have any questions or need additional information, please contact us Phone: 440-248-4700 Toll Free: 800-535-2725 Fax: 440-248-4700 www.rugerindustries.com E-mail: info@davidround.com Below is a list of standard accessories that you should have received with your RC1000 • Operator’s Manual • Swivel Hook with Safety Latch • Extension Boom •...
-
Page 3: Table Of Contents
Designers & Manufacturers of Hydraulic Load Lifting and Material Handling Equipment Contents General Information.................1 Receiving and Pre-operational Instructions..........1 Returned Goods Authorization............2-3 Insert Sheets................4-5 Maintenance Instructions..............6 Recommended Parts..............7-9 Jack Inspection Check List................10 Jack Service Instructions................11 Operational Steps................12 Lubrication..................13 Safety Tips for Using Ruger Cranes..........14 Warranty.................15-17... -
Page 4: General Information
3. Terms are Net 30. Minimum order is $50.00 . All parts are FOB Solon, Ohio. 4. Quality at Ruger starts with raw materials which are inspected to insure our products will be of good quality and free from defects. Each Economy Crane is tested completely and checked before shipment. - Page 5 RECEIVING PROCEDURES BEFORE ACCEPTING DELIVERY FROM THE CARRIER In accepting this shipment from Ruger Industries, Inc., the carrier has acknowledged receipt in good condition and complete as shown on the packing list and/or Bill of Lading. RECEIVING INSPECTION CHECK LIST...
-
Page 6: Returned Goods Authorization
RETURNED GOODS AUTHORIZATION RETURNED GOODS AUTHORIZATION number must be assigned by the Ruger customer service department for approved returns. This number must appear on all accompany- ing paperwork. When calling for a RETURNED GOODS AUTHORIZATION number the following information must be supplied:... - Page 7 ANSI/ASME PALD-12C standards. Prices, Specifications, and Options are subject to Change Without Notice. Meets ANSI Z.535 All Ruger products are shipped F.O.B. Solon, Ohio 44139 Unit Ships-NMFC #118900 Sub 3 - Class 125 Shipping Wt. 210 lbs FAX: 440-248-8544 E-mail: info@davidround.com...
- Page 8 VERSATILE COMPACT AFFORDABLE RELIABLE MODEL: RC1000 ModelRC ..........1000 Capacity ..........1000 lbs Overall base length ........53 1/8” Overall width ..........35” Overall height ..........72 1/2” Width between legs ........28 3/4” Overall boom length ........45” Max. O.A. boom length with extension ....52” Boom height (lowest position) ....34”...
-
Page 9: Maintenance Instructions
MAINTENANCE INSTRUCTIONS NOTE: There is an overload relief valve built into the hydraulic system of every new Ruger Crane. This safety valve is set at the factory, under measured loadings, and opens at about 10% over the rated capacity, preventing the crane from lifting. -
Page 10: Recommended Parts
RECOMMENDED PARTS... - Page 11 RECOMMENDED PARTS COMPLETE JACK ASSEMBLIES: 09-004 AND 09-005 REPAIR KITS PACKING KIT: #768-2 CONSISTS OF ITEMS NO. 2,5,9,28,32 (ALL CRANES) PUMP PISTON KIT: #768-3 CONSISTS OF ITEMS NO. 23,24,25,26 (ALL CRANES) CHECK VALVE KIT: #81053 CONSISTS OF ITEMS NO. 8,9,33,34,35,36 RELIEF VALVE KIT: #80360 CONSISTS OF ITEMS NO.
- Page 12 ORDER PARTS BY PART NAME AND NUMBER. BE SURE TO INCLUDE MODEL AND SERIAL NUMBER. All parts are FOB Solon, OH. Terms are Net 30. Minimum order - $50.00. MODEL ________________________ SERIAL NUMBER ___________________________ RC1000 4 5 0 1 0 0 0 7 5 0 Capacity Tag - Found on boom of crane ITEM NO.
- Page 13 OPERATIONAL STEPS Standard Boom Extension. To operate the boom extension, first remove the pin that holds the boom in place. After removing the pin pull the extension boom until one of the other two pin holes is revealed and place the pin in the desired hole location .
-
Page 14: Jack Inspection Check List
JACK INSPECTION CHECK LIST COMPONENTS INSPECT FOR CORRECTIVE ACTION STRAIGHTNESS, SCORE MARKS, PUMPING PISTON, ITEM PITTING, HEAD OR HOLE REPLACE IF ANY OF THESE DEFORMATION, LEAKAGE CONDITIONS ARE FOUND. AROUND PACKING NUT. REPLACE. ALIGNMENT OF PUMP LINKAGE PINS, ITEMS WORN OR BENT. PISTON IS DEPENDENT ON THESE 16, 19, &... -
Page 15: Jack Service Instructions
JACK SERVICE INSTRUCTIONS If the crane fails to hold or lift its seated load, it could be the result of one or a combination of several problems. All parts referenced are shown in jack breakdown. Remove jack from crane for all service work. A. -
Page 16: Lubrication
LUBRICATION ITEM DESCRIPTION WHEN BOOM PIVOT POINT CHASSIS LUBE APPLY MONTHLY JACK MOUT PIVOT POINT CHASSIS LUBE APPLY AS NEEDED CYLINDER EARS ON BOOM CHASSIS LUBE APPLY AS NEEDED LOAD WHEEL AXLES CHASSIS LUBE APPLY MONTHLY (DO NOT SPRAY WHEELS) STEERING WHEEL AXLES CHASSIS LUBE APPLY MONTHLY (DO NOT SPRAY WHEELS) -
Page 17: Safety Tips For Using Ruger Cranes
SAFETY TIPS FOR USING RUGER CRANES Operator Keep hands and feet clear of crane base and wheels. Safe operation of this Also, in facing away from equipment is your crane while pulling, maintain responsibility. distance to prevent crane NO PERSON shall operate... -
Page 18: Warranty
(8) The products have not been sold, leased or otherwise transferred out of title and control of the original purchaser. (9) All other parts used in the manufacturing of Ruger Industries Products will carry the individual part manufac- turers warranty. - Page 19 It should be verified that the equipment will do the job for which it was ordered for. If a problem occurs with a Ruger product, the ideal solution will get the equipment back into service promptly with costs of the repair paid by the appropriate party -- either the...
- Page 20 1. Proceeding with repairs and submission of invoices for factory payment or credit, relying on the fairness of Ruger's service people to back up the customer, the distributor and the equipment to the maximum responsible limit subject to the terms of the warranty itself, or..
