KI Basic Adjustable CPU Holder Assembly Instructions

1 ⁄ x 1"
4
torx head screw
Figure 1
1330 Bellevue Street • P. O. Box 8100 • Green Bay, WI 54308-8100 • Tel 1-800-424-2432 • www.ki.com
A s s e m b l y I n s t r u c t i o n s
B a s i c A d j u s t a b l e C P U H o l d e r
3 ⁄ " hole
16
( 3 ⁄ " deep max.)
4
glide plate
slotted bracket
© 2006 KI All Rights Reserved • Litho in USA • Code KI-60530R1/KI/PDF/806
A u g u s t 2 0 0 6
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and injury.

Tools Provided:

•T-20 Torx Driver (#8 screw)
•T-30 Torx Driver ( 1 ⁄ " screw)
4
• 3 ⁄ " Allen Wrench (set screw collar)
32

Tools Required:

• ⁄ " Open End Wrench,
11
16
• 7 ⁄ " Open End Wrench or Socket
16
•Power Drill
• 3 ⁄ " Drill Bit
16
Note: In some installations,
the CPU may not be available
for placement into the CPU Holder
until a later time. Follow these
directions using an accurate
measurement of the CPU height
and width as a guideline.
1. Position the glide plate under
the worksurface. Be sure that the
glide plate is parallel and placed
2" from the front edge of the
worksurface (1" on 24" deep
worksurfaces). Mark the four
mounting holes through the
plate onto the underside of the
worksurface (Figure 1).
2. Using a ⁄ " drill bit to a maximum
3
16
depth of ⁄ ", drill the four mounting
3
4
holes in the underside of the
worksurface. Be careful not to
pierce through the top of the
worksurface when drilling the
holes. Attach the glideplate to the
worksurface with four ⁄ x 1" torx
1
4
head screws. Tighten each screw
only halfway, leaving the glide
plate to hang down 1 ⁄ " from the
2
surface (Figure 1).
3. Slide the slotted bracket over the
end of the glide plate. Tighten the
screws into the worksurface
(Figure 1).
Note: If the CPU is not available
to be placed into the holder until a
later time, skip step 4 and go onto
step 5, through 10. When a CPU is
to be installed along with the CPU
Holder, follow steps 4 through 10
but skip step 5.
