- Page 1 Installation Manual 24 Inch Stainless Steel Dishwasher F24DWS250SS...
-
Page 2: Table Of Contents
CONTENT IMPORTANT SAFETY INSTRUCTIONS..................2 INSTALLATION PREPARATION ....................5 PREPARE DISHWASHER....................PREPARE AND ROUTE THE ELECTRICAL SUPPLY..............7 PREPARE HOT WATER LINE AND POWER CORD HOLE............8 INSTALLATION..........................9 PREPARE HOT WATER LINE AND POWER CORD HOLE............9 STEP 1 - HANDLEBAR ASSEMBLY....................10 STEP 2 - CHECK DOOR BALANCE....................10 STEP 3 - INSERT DRAIN HOSE AND POWER CORD THROUGH CABINET.......11 STEP 4 - SLIDE DISHWASHER PARTIALLY INTO CABINET............11... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS BEFORE YOU BEGIN WARNING Please read these instructions completely and carefully. IMPORTANT— Observeallgoverningcodesandordinances. Note to Installer - Be sure to leave these instructions for the consumer's and local inspector'suse. Note to Consumer-Keep these instructions with your Owner’s Manual for future reference. - Page 4 INSTALLATION REQUIREMENTS TOOLS AND PARTS Materials for New Installations Only: Waste tee for house plumbing, if applicable Gather the required tools and parts before starting installation. Hand shut-off valve Coupler for extending drain line, if applicable PARTS SUPPLIED dishwasher to underside of countertop (in literature package). Waste Tee Hand Shut-Off Valve Coupler...
- Page 5 IINSTALLATION REQUIREMENTS For New Installations Only: Tubing cutter Hole saw set Drill and appropriate bits Tubing Cutter Drill and Bits Hole Saw Set...
-
Page 6: Installation Preparation
INSTALLATION PREPARATION DRAIN PREPARATION Method 2 -High Drain with Waste Tee or Disposer Provide a method to attach drain hose to underside of countertop. The type of drain installation depends on answers to the following questions: Do local codes or ordinances require an air gap? Will waste tee or disposer connection be less than 18"... -
Page 7: Prepare And Route The Electrical Supply
INSTALLATION PREPARATION PREPARE AND ROUTE THE ELECTRICAL NOTE: A grounded 3 prong outlet is required inside a cabinet next to the dishwasher cabinet opening. SUPPLY You Must Have: 120-voit, 60Hz, AC-only,12-amp, fused electrical supply. We Recommend: A time-delay fuse or circuit breaker. A separate circuit. -
Page 8: Prepare Hot Water Line And Power Cord Hole
INSTALLATION PREPARATION Water Line Connection PREPARE HOT WATER LINE AND POWER Turn off the water supply. CORD HOLE Install a hand shut-off valve in an accessible location, such as under the sink. (Optional, but strongly recommended and may be required by local codes.) area shown in Figure F. -
Page 9: Installation
INSTALLATION PREPARE HOT WATER LINE AND Water Line Connection Turn off the water supply. POWER CORD HOLE Install a hand shut-off valve in an accessible location, such as under the sink. (Optional, but strongly recommended and may be required by local codes.) Connect one end of inlet line(a) to the 3/4-inch FHT(b)and area shown in Figure F. -
Page 10: Step 1 - Handlebar Assembly
INSTALLATION STEP 2 - CHECK DOOR BALANCE BEFORE YOU BEGIN STEP 1 - HANDLEBAR ASSEMBLY Use a hex wrench to install the outside door handle, ※This step is only applicable to the W60C4A411B model. Haxtun tools CR-V 4mm 30°~90° balance 3~7KG Figure H Hexagon wrench-M6... -
Page 11: Step 3 - Insert Drain Hose And Power Cord Through Cabinet
INSTALLATION STEP 4 - SLIDE DISHWASHER PARTIALLY STEP 3 - INSERT DRAIN HOSE AND INTO CABINET POWER CORD THROUGH CABINET DO NOT PUSH AGAINST FRONT PANEL WITH KNEES. DAMAGE WILL OCCUR. Slide dishwasher into the opening a few inches at a time. Maximum Drain Hose Length 10'... -
Page 12: Step 5 - Position Dishwasher Under Countertop
INSTALLATION STEP 5 - POSITION DISHWASHER UNDER STEP 6 - LEVEL DISHWASHER COUNTERTOP IMPORTANT: Dishwasher must be level for proper dish rack operation and Check to be sure that wires are secure under the dishwasher and wash performance. not pinched or in contact with other dishwasher components. Place level on door and rack track inside the tub as shown to Push dishwasher into cabinet. -
Page 13: Step 7 - Fixation Of Dishwasher
INSTALLATION STEP 7 - FIXATION OF DISHWASHER Adjust the height by turning the feet to make sure the dishwasher is level. Fixing the dishwasher with the cabinet by turning the screws. Plug the four hole plugs into the holes in the sketch map. ST4*26 hole plug Adjust the front feet... -
Page 14: Step 8 - Connect Drain Line
INSTALLATION Water Line Connection STEP 8 - CONNECT DRAIN LINE Connect drain line to air gap, waste tee or disposer using either FOLLOW ALL LOCAL CODES AND ORDINANCES. previously determined method. Method 1 -Air gap with waste tee or disposer tions on the air gap, waste tee or disposer. -
Page 15: Step 9 - Connect Power Supply
INSTALLATION STEP 9 - CONNECT POWER SUPPLY IMPORTANT: When connecting drain line to disposer, check to be sure that drain Power supply cord-Plug into a grounded 3 prong outlet. plug has been removed. DISHWASHER WILL NOT DRAIN IF PLUG IS LEFT IN PLACE. Remove Disposer Plug TIP: Avoid unnecessary service call charges. -
Page 16: Step 10 - Pre-Test Checklist
WARRANTY REGISTRATION INSTALLATION STEP 10 - PRE-TEST CHECKLIST WARNING Review this list after installing your dishwasher to avoid charges for a service call that is not covered by your warranty. Read the Owner’s Manual for operating instructions. Electrical Shock Hazard Plug into a grounded 3 prong outlet. -
Page 17: Step 11 - Dishwasher Wet Test
INSTALLATION STEP 11 - DISHWASHER WET TEST STEP 12 - LITERATURE Plug power cord into outlet. Be sure to leave complete literature package and installation Power on and select Rinse Wash program. instructions with consumer. Close door and press the start buttons. Check to be sure that water enters the dishwasher.
