- Page 1 Operating Instructions for ASCOLINE 850 MEH 3xx, 5xx, 7xx Electric range with glass ceramic plate Quality and Competence in Stainless Steel...
-
Page 2: Table Of Contents
Non-observance of the safety instructions means danger to persons (injury) or damage to the equipment Hot surfaces. Contact can lead to burns. ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice! -
Page 3: Details Of The Equipment
Never try to extinguish fat or oil using water! Put on the lid, switch off the appliance and remove the pot carefully from the hob. ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice! -
Page 4: Instructions For Transport
• Before repair work is started, the equipment must be disconnected on all poles from the power (using isolating equipment in the customer's supply, e.g. contact breakers). 3.3 Instructions for transport • Transport ascobloc equipment only in the original packaging. This avoids unnecessary damage and expense. • Check equipment for damage. -
Page 5: Proper Use Of The Equipment
If the equipment is to be taken out of use, set all knobs to “zero”. ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice! -
Page 6: Cleaning
Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice! -
Page 7: Repair And Maintenance
Fuse in customer supply is open Restore supply ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice! -
Page 8: Customer Service
A repair may only be performed by trained, qualified specialists. Please give us the equipment number and the type designation that are on the equipment type plate. The plate is located on the front cover A of the equipment (see connection diagram). 7.2 Customer service ascobloc Customer Service: Tel. +49 351 4533–384 +49 351 4533–379 E-mail kundendienst@ascobloc.de... -
Page 9: Spare Parts
Tubular heating element 6000 W MEH 503/505/703/705 09/3347 Tubular heating element 3000 W ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice! - Page 10 = Spare parts only for appliance with pot detection MEH 30x.110/MEH50x.110/MEH70x.110 X = replacement or repair only by authorised specialist company ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice!
-
Page 11: Illustrations
Oven (without oven floor, side-supports for slide-in trays, partition plate for fan Figure 2 circulation heating) ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice! - Page 12 Radiant heater (shown is MEH xxx.110 with pot detection and circuit board Figure 3 sensor electronics) ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice!
-
Page 13: Declaration Of Conformity
General requirements DIN EN 55014-1:2007-06 Electromagnetic compatibility - Requirements for household appliances, ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice! - Page 14 Equipment for commercial kitchens - Ranges - Requirements and testing Dresden, 31 March 2010 p.p. R. Ziegler Technical Director ascobloc Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany Tel.: +49 351 4533-0 Fax: +49 351 4537-339 E-mail: service@ascobloc.de mehc3xff, last update: 31/03/2010 Subject to change without notice!
