Summary of Contents for Jackery EXPLORER 1500
- Page 1 PORTABLE POWER STATION JACKERY EXPLORER 1500 USER GUIDE...
- Page 2 Jackery Portable Solar Generator systems can keep your equipment running indoors and outdoors with multiple power outputs, storage capacities, and charging methods. Our award-winning power station product line produces eco-friendly power, which allows you to charge/power devices from the power supply with the touch of a button.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS Please carefully read and understand this manual before using this product to avoid possible injury or property damage. Keep this manual for future reference. a) To reduce the risk of injury, close supervision is necessary when the product is used near children.
- Page 4 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 5: Table Of Contents
Warranty ........14 ii. Charging from Solar .....07 Package List ......15 iii. Charging in the Car .....08 Français ........16 Using Your Jackery Explorer 1500 Deutsch .........25 i. How to use ........09 Español ii. Best-Use Strategy ........35 .......09 Italiano iii. Cold Weather Usage ....09... -
Page 6: Get To Know Your Equipment
Get to Know Your Equipment E1500 Body LCD Screen Button DC Button LED Flashlight DC Input Car Port USB-C Output AC Output USB-A Output AC Button Specifications 35.6 x 26.4 x 32.3cm SOS LED 16kg / 35.27lbs 14 x 10.4 x 12.7in Weight Dimensions LED Flashlight... - Page 7 Discharging Indicator( The battery is being used.) AC Power Indicator(Inverter is being used to power AC devices) When the Explorer 1500 is being charged, the orange circles around the battery percentage will light up in sequence. When charging other devices, the orange circle will stay on.
- Page 8 Output Power (W) Before turning the power on, ensure total power consumption does not exceed 1800W. If the Jackery Explorer total output exceeds 1800W, it will shut off. Display The normal Auto-Power-Off-Display time frame is 30 seconds. If you would like to set the display on more than 30 seconds, please double press the DISPLAY button.
- Page 9 When the AC power is turned on, the fan will not automatically run. The E1500 uses an intelligent temperature control that only uses the fan when needed to cool the unit. How to reset the Explorer 1500 Please hold the display power button and USB button simultaneously for at least 13 seconds to reset the battery.
-
Page 10: How It Works
How it Works 400W of Solar Car Charge Wall Charge (Sold separately) (100W Max) (250W) 5-10 Hours 17 Hours 6.5 Hours (Based off max input) CHARGE IT WHAT IT POWERS +MORE Coffee maker Car Fridge Drone Motion Camera Toaster (1120W) (60W) (90W max) (5W max) -
Page 11: Charging Your Jackery Explorer
Charging from the wall Plug your Jackery Explorer into any wall outlet with 300W AC wall charger. When the power station is in charge, the blue LED on the INPUT port will light up and the battery segment in the BATTERY DISPLAY will flash. -
Page 12: Charging From Solar
SolarSaga 100 Explorer 1500 Two SolarSaga 100W for the Explorer 1500 Two SolarSaga 100W solar panels （not included）can quickly charge the Explorer 1500 within 8.5 hours. Solar recharging steps: Find the DC interface on the back of SolarSaga 100W; Connect the DC interfaces of 2*SolarSaga 100W with the Solar Charge Adapter;... -
Page 13: Charging In The Car
Avoid applying external pressure to the solar panels; doing so will damage the solar panels and cause the output to decrease. Charging in the Car Plug the 8mm DC barrel connector of the car charging plug into the Explorer 1500, and plug the other end into your 12V car port. AUTO... -
Page 14: Using Your Jackery Explorer 1500
LED on the power button illuminates. Make sure to turn it off after use to save power. Plug in and power your equipment anytime, anywhere. Plug your Jackery Explorer 1500 into a power source (AC adapter or Solar Charger, etc.) when not in use to ensure that the product remains fully charged. -
Page 15: Storage And Downtime Maintenance
Jackery Explorer is charged and ready to go at any time. NOTE: Fully charge your Jackery Explorer every 3 months and store it in a cool, dry place if you can’t keep your Jackery Explorer plugged into a power source during storage. If the Jackery Explorer has not been used for several months, it may require several charge cycles to restore accurate display of the battery percentage and time remaining values on-screen. - Page 16 Ports 3*110V AC Inverter (output, pure sine wave) 110VAC 60Hz, 16.4A (1800W, 3600W surge) 1*12V Car Port (output) 12V, up to 13A (160W max), regulated 1*USB-A Port (output) 5V, up to 2.4A (12W max), regulated 1*Quick charge 3.0(output) 5-12V,up to 3A (18W max) 1*USB-PD Port (output) 5 - 20V, up to 3.0A (60W max), regulated 2*Charging Port (input, 8mm)
-
Page 17: Questions And Troubleshooting
A: The AC output port can charge/power devices that operate at less than 1800 watts. Q2: Can the Explorer 1500 be charged while using? A: Yes, the Explorer 1500 supports pass-through charging. But we don't suggest it because doing so will cause damage to battery life. -
Page 18: Troubleshooting
Q11:Are the output ports regulated, and if so, which ones are regulated? A: All output ports of Jackery power stations are regulated. The voltage won't change when the battery power decreases. Q12: Are the batteries inside replaceable? A: No, the batteries inside of Jackery power stations are not replaceable. -
Page 19: Warranty
WARRANTY Note: We only provide the warranty for the buyer who purchased on Amazon (Jackery Inc) or through the Jackery website . Limited Warranty Jackery Inc. warrants to the original consumer that the Jackery product will be free from defects in workmanship and material under normal consumer use during the applicable warranty period identified in the 'Warranty Period' section below, subject to the exclusions set forth below.This... -
Page 20: Package List
Package List Check that you received all accessories (Car Charger, AC Charger, 2*Solar Charge, Adapters, and User Manual). If any charger cables are missing, please feel free to contact us at hello@jackery.com. Jackery Explorer 1500 Car Charger AC Charger 2*Solar Charge Adapters...
