ASSEMBLY INSTRUCTIONS
90DEG CORNER SCREEN 2
PARTS & HARDWARE
SCREEN A
QUANTITY: 1
SCREEN B
QUANTITY: 2
MAIN POST
QUANTITY: 2
Thank you for your order!
For questions or concerns regarding your order or installation, please contact customer service via email at
customercare@ezobord.co.uk, or call us at 01843 666111 (International +44 1843 666111).
Visit our website at
shop.ezobord.com/uk
CAP
QUANTITY: 2
SHELF
QUANTITY: 2
BOTTOM TRIM
QUANTITY: 2
PAGE 1/5
