4050 Dual Port Antenna Switch Unit
(P/N BCA40506)
The Barrett 4050 HF SDR Transceiver can support a secondary antenna through the use of a Dual Port Antenna Switch Unit. This
allows the transceiver to be connected to two antennas instead of one. Two examples of dual antenna use are a mobile unit
utilising both a 2019 Automatic Tuning Mobile HF Antenna and a 2018 Mobile Magnetic Loop Antenna, or a base station with
one long wire antenna set up orientated North-South with a second long wire set-up East-West.
Example Connection Diagram
1
2019 Automatic Tuning Mobile HF Antenna - P/N BC401900
2
Interface and coaxial cable - 6 metres - P/N 4019-00-02
3
Dual Port Antenna Switch Unit - P/N BCA40506
4
2018 Mobile magnetic loop HF antenna - P/N BC201801
5
Ground (earth)
6
Coax cable - P/N BCA90028
ATU cable - P/N 2065-00-06
Ground (earth)
4050 HF SDR Transceiver (rear) - P/N BC405000
BCM40506/2
Advertisement
Table of Contents
Related Manuals for Barrett 4050
Summary of Contents for Barrett 4050
- Page 1 (P/N BCA40506) The Barrett 4050 HF SDR Transceiver can support a secondary antenna through the use of a Dual Port Antenna Switch Unit. This allows the transceiver to be connected to two antennas instead of one. Two examples of dual antenna use are a mobile unit utilising both a 2019 Automatic Tuning Mobile HF Antenna and a 2018 Mobile Magnetic Loop Antenna, or a base station with one long wire antenna set up orientated North-South with a second long wire set-up East-West.
- Page 2 Operation Before first use of dual antennas, the Barrett 4050 HF SDR Transceiver must be properly configured. For further information on the operation of a Barrett 4050 transceiver, please refer to the Barrett 4050 HF SDR Transceiver Operating and Installation Man- ual (BCM40500).
