- Page 1 INSTALLATION AND PROGRAMMING GUIDE Bluetooth and Proximity Reader...
-
Page 3: Table Of Contents
CONTENTS Get Started ..........1 Reset the Reader ............ 13 Reset to Defaults ..........13 Procedure ..............1 What’s Included ............1 Factory Reset ............13 What You’ll Need ............1 Compatibility ............14 Panels and Door Controllers ......14 Step 1: Install the Reader ......2 Access Control Modules ........ -
Page 4: Get Started
SR3 Bluetooth and Proximity Readers support Mobile Credentials and 125 kHz proximity credentials. The reader comes with two mounting options, mullion or single‑gang, and is suitable for indoor or outdoor use. The SR3 uses the Wiegand reader protocol to communicate with door controllers or access control modules. -
Page 5: Step 1: Install The Reader
Bracket Mount Base (optional) with Side Marked TOP Facing Up Wall Anchor (optional) Wires from Access Control Module, Keypad, or Door Controller Wall Anchor (optional) Reader Base Mounting and Base Orientation SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 6: Wire The Reader
Directional Antenna (optional) None ‑ Do Not Cut None ‑ Do Not Cut None ‑ Do Not Cut * If connected, the orange wire (beeper) mimics keypad beeping. Table 1: Wire Connections SR3 Installation and Programming Guide | Digital Monitoring Products... - Page 7 Z4+ Z4– 734 Series Access Control Module Piezo – RELAY WIEGAND DATA PROG KYPD IN KYPD OUT READ LED XMT LED * Orange connection to RA terminal is optional. 734 Wiring Example SR3 Installation and Programming Guide | Digital Monitoring Products...
-
Page 8: Attach The Cover
Use the included #4 case screw to secure the reader cover onto the base. Do not overtighten the screw. Apply power to the reader’s connected power source. After the reader powers on, the LED remains steady yellow. Hook Press down Press in Insert screw and tighten Installing the Cover SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 9: Step 2: Enroll & Associate The Reader
“56‑Bit Card Format”. Configuring the Reader in Tech APP 56‑Bit Card Format WIEGAND CODE SITE CODE SITE CODE USER CODE USER CODE USER CODE NAME LENGTH POSITION LENGTH POSITION LENGTH DIGITS BLUETOOTHFORMAT SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 10: Step 3: Purchase Credentials
This section covers how an Administrator purchases credentials for a customer in Dealer Admin. These steps can only be completed after the SR3 Bluetooth Reader is installed and associated with a customer’s system in Tech APP. Note: To purchase and issue credentials in Dealer Admin, you must either have an Administrator role or a custom role with Mobile Credential permissions. -
Page 11: Step 4: Assign A Mobile Credential
Virtual Keypad, or if a user’s phone is factory reset ▶ If a user doesn’t bind an assigned credential to their phone within 2 weeks, the credential expires and returns to the customer’s pool of credentials SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 12: Step 5: Bind A Credential To A Device
Find the credential that is labeled as Unlinked Credential and tap Link to this Phone. When the credential is successfully bound, the link text disappears and the label changes to Linked Credential. Binding a Mobile Credential to the Device in Virtual Keypad SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 13: Step 6: Use A Credential
You can hide these notifications from your device’s Settings menu. When you receive a notification from Virtual Keypad after using your mobile credential, swipe left on the notification and Settings. Turn off Mobile Credential Notifications. SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 14: Reference
Yellow, steady White, steady Blue, spinning Green, flash No power Powering on Connected to power, Enrolled, waiting Searching for Access ready for enrollment for credential credential granted All Reader LED Operations SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 15: Troubleshooting
• Perform a factory reset, then re‑enroll it re‑enrolled, and it still doesn’t or hardware issue work Tried everything above and • Issue beyond installer scope • Call Tech Support at 1‑888‑4DMPTec the reader still doesn’t work SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 16: Reset The Reader
Follow the steps in this guide to Enroll & Associate the Reader. If none of the previous steps fix issues with the reader, call DMP for assistance. Tech Support at 1‑888‑4DMPTec SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 17: Compatibility
1386 ISOProx II® card Ordering Information Log in to Dealer Admin to purchase and issue mobile credentials. Visit Buy.DMP.com to order SR3 Bluetooth Readers, Door Controllers, Access Control Modules, prox credentials, and more. SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 18: Specifications
FCC Part 15 RFID Reader FCC ID: 2ANJI‑SR3 ▶ Industry Canada ID: 10727A‑SR3 Underwriters Laboratory (UL) Listed ANSI/UL 294 Access Control System Units Level I Destructive Attack, Line Security, Standby Power Level III Endurance SR3 Installation and Programming Guide | Digital Monitoring Products... -
Page 19: Fcc Information
FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made by the user and not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
