docherty Excelsior Manual page 4

4
Components
Straight
Length
Adjustable
Length
o
15 Elbow
30 o Elbow
o
45 Elbow
For matt black option add a 'P' to the end of product code to get priced in black
Excelsior
Ø
Nominal Length
Effective Length (L)
Ø125mm
Ø150mm
L
Ø180mm
Ø200mm
Ø
L
Ø
B
L
A
Ø
B
L
A
Ø
B
A L
200mm
167mm
EX2013
EX2015
EX2018
EX2020
Nominal Length
Effective Length (L)
Ø125mm
Ø150mm
Ø180mm
Ø200mm
Diameter (Ø) 125mm (5") 150mm (6")
Height (L) 84mm 84mm
A 61mm 63mm
B 48mm 50mm
EXB1513 EXB1515
Code
Diameter (Ø) 125mm (5") 150mm (6")
Height (L) 69mm 81mm
A 64mm 77mm
B 64mm 64mm
EXB3013 EXB3015
Code
Diameter (Ø) 125mm (5") 150mm (6")
Height (L) 43mm 42mm
A 79mm 83mm
B 70mm 74mm
Code EXB4513 EXB4515
500mm 1000mm
467mm 967mm
EX5013 EX10013
EX5015 EX10015
EX5018 EX10018
EX5020 EX10020
280mm - 500mm
247mm - 467mm
EXPP13
EXPP15
EXPP18
EXPP20
180mm (7") 200mm (8")
EXB1518 EXB1520
180mm (7") 200mm (8")
EXB3018 EXB3020
180mm (7") 200mm (8")
EXB4518 EXB4520
