Axon TASER 7 Quick Start Manual

COMPLETE TRAINING FIRST.
1
CONFIRM THE CEW IS READY FOR USE
2
Check with your armorer to be sure rmware is up to date, the CEW has
the correct set-up for your agency and that the weapon, cartridges, and
battery packs have been properly assigned to you.
INSERT THE BATTERY
3
A) Insert the battery pack into the weapon. Press rmly until
you hear both latches "click."
B) Inserting a new battery pack will synchronize the weapon's logs to
the battery pack and may update the CEW rmware automatically.
Do not remove the battery pack from the CEW until the hourglass
icon disappears from the CID.
TURN THE CEW ON AND OFF
4
A) Point the CEW in a safe direction.
B) Shift the safety switch to the up
(ARMED) position.
If you need assistance, please visit www.axon.com or contact technical support at: US: 1-800-978-2737; Australia: +1 800-051-2069; other international: +1 480-463-2170
C O N D U C T E D E N E R G Y W E A P O N
Q U I C K S T A R T G U I D E
If the battery pack is fully charged,
the Critical Information Display (CID)
should look like this:
C) Shift the safety switch to the
down (SAFE) position.
WORKING WITH CARTRIDGES
5
Point the CEW in a safe direction. Be sure the safety is in the down
(SAFE) position. Do not put your hands in front of the cartridges.
Remove the cartridges from the safety clip.
CARTRIDGE COLOR CODE
BLACK = Live Cartridge,
Stando (3.5°) or
Close-quarter (12°).
For eld use.
BLUE = Hook and Loop
Training (HALT) Cartridge,
Stando (3.5°) or
Close-quarter (12°).
For training use only.
DO NOT USE IN FIELD.
RED = Inert Training
Cartridge (no probes).
For training use only.
DO NOT USE IN FIELD.
