HARDWARE
PARTS LIST:
A. Hex Screw
x 32 pcs
(50 mm, 2 in)
B. Cam Bolt
1
x 4 pcs
x 2
(36 mm, 1 3/8 in)
C. Cam Lock
x 4 pcs
D. Cross Dowel
Bolt x 4 pcs
(58 mm, 2 1/4 in)
E. Cross Dowel
Nut x 4 pcs
6
Allen Wrench
x 1 pc
The following tool
is required for
assembly:
8
R
Phillips Screwdriver
x 10
CAUTION:
ADULT ASSEMBLY REQUIRED. Hardware contains
small screws with sharp points. Keep unassembled
parts out of the reach of small children.
All manuals and user guides at all-guides.com
Heart Table and Chair Set
5
x 2
2
4
x 2
x 2
3
x 2
7
9
USE AND MAINTENANCE:
-Use on level surfaces only
-Please check assembly at regular intervals, and
frequently tighten hardware if necessary. If
maintenance is not carried out, the product could
cease to function properly.
Parts List
Assembly Instructions
NOTE: Once the two pieces of the plastic bin are connected, mechanism is permanent.
Do not attempt to separate the two pieces once assembled.
Step 1
Place Bottom through Top.
To order replacement parts, please visit www.kidkraft.com
Bin
Step 2
Pull up Top with one hand and push down Bottom at the
same time until the two parts lock. Make sure that the
six "U" hooks have been securely locked.
Bottom
Top
*Repeat for lavender bins.
Step 3
10
Pink
x 2
Patent Pending
WARNING:
CHOKING HAZARD. Small parts and sharp points, not suitable
for children under 3 years.
Item #26913A
Bottom
Top
11
Lavender
x 2
Customer Service
1-800-933-0771
www.kidkraft.com
