homechoice Orlando Assembly Instruction Manual

L-shaped sofa

Advertisement

Quick Links

Please follow these guidelines for safe assembly:
1) Because this item is large, we recommend that two people assemble it together,
in the room in which it will be used.
2) Get the best from your sofa:
Assemble it on a soft, clean surface.
Only use the hardware provided. It is recommended that you do not use
any other tools or power tools for the assembly.
Remember not to over-tighten screws or drag the sofa along the ground
during assembly or normal maintenance.
HomeChoice will not be held liable for damages caused by improper assembly.
3) Please make sure that you have all the parts and hardware items listed before you start
assembling your sofa. If you find that something is missing, please do not assemble.
Contact our Customer Service on 0861 466 324.
Orlando L-shaped Sofa
assembly instruction
