NDA1402
autodefrost
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open fl ame.
4. Immediately call your gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
!
WARNING
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional infor-
mation consult a qualifi ed installer, serv-
ice agency or the gas
supplier.
USA
Service Offi ce
Dometic Corporation
2320 Industrial Pkwy.
Elkhart, IN 46516
Phone: 574-294-2511
825126500
©Dometic Corporation
LaGrange, IN 46761
®
Si vous sentez une odeur de gaz:
1. Ouvrez les fenêtres.
2. Ne touchez à aucun interrupteur.
3. Éteignez toute fl amme nue.
4. Avertissez immédiatement votre
Ne pas entreposer ni utiliser de l'essence
ni d'autres vapeurs ou liquides infl amma-
bles à proximité de cet appareil ou de tout
autre appareil.
Une installation, un réglage, une modifi -
cation, une réparation ou un entretien non
conforme aux normes peut entraîner des
blessures ou des dommages matériels.
Lisez attentivement le mode d'emploi
fourni avec l'appareil. Pour obtenir de
l'aide ou des renseignements supplémen-
taires, consultez un installateur ou un
service d'entretien qualifi é ou le fournis-
seur de gaz.
Corporate Offi ce
2320 Industrial Parkway Elkhart, IN 46515
For Service Center Assistance
Call: 800-544-4881
USER
MANUAL
REFRIGERATOR FOR LP-GAS
& ELECTRIC OPERATION
POUR VOTRE SÉCURITÉ
fournisseur de gaz.
POUR VOTRE SÉCURITÉ
!
AVERTISSEMENT
®
CANADA
Dometic Corporation
46 Zatonski, Unit 3
Brantford, ON N3T 5L8
CANADA
Phone: 519-720-9578
MO-M 0608

Advertisement

Table of Contents
loading

Related Manuals for Dometic NDA1402

Summary of Contents for Dometic NDA1402

  • Page 1 USER ® MANUAL NDA1402 autodefrost REFRIGERATOR FOR LP-GAS & ELECTRIC OPERATION FOR YOUR SAFETY POUR VOTRE SÉCURITÉ If you smell gas: Si vous sentez une odeur de gaz: 1. Open windows. 1. Ouvrez les fenêtres. 2. Don’t touch electrical switches.
