- Page 1 ULS Manufacturing ‘ULSHIM’ 14 x 15 watt RGBWA+UV Pixel Map IP65 RATED WWW.ULTRALIGHTSOUND.CO.UK...
-
Page 3: Risk Of Electric Shock
Should the fuse in the plug need replacing ensure a 3amp fuse with a British kite mark is used. ULS manufacturing will not accept liability for any damages caused by the non-observance of this manual, or any modification to this device. - Page 4 Thank you for purchasing our premium Led Batten. Rugged Design and build for out on the road use with a feature set to rival existing products on the market. Key features Simple 2 channel Dmx control mode or advanced 6, 8, 11, 17, 47, 84 and 86 Dmx channel modes Pixel mapping ability with Dmx control of each 6 colours per led.
- Page 5 2 channel Dmx mode - 2ch Dmx 1 Colour macro Dmx 2 Speed slow - fast 6 channel Dmx mode - 6 ch Dmx 1 0 - 100% Dmx 2 Green 0 - 100% Dmx 3 Blue 0 - 100% Dmx 4 White 0 - 100%...
- Page 6 control 11 Channel Dmx Mode of each background colour colour available control from from channel Strobe Speed channel 5 6 - 11 Master dmx 1 dimmer dmx 2 Strobe open - fast dmx 3 0-005 no function 006-015 user defined chase effect 1 016-025 user defined chase effect 2 026-035...
- Page 7 17 CHANNEL DMX MODE 17CH control of each background colour colour available control from from channel Strobe Speed channel 5 6 - 11 Master dmx 1 dimmer dmx 2 Strobe open - fast dmx 3 0-005 no function 006-015 user defined chase effect 1 016-025 user defined chase effect 2 026-035...
- Page 8 control of each background colour 47 CHANNEL DMX MODE 47CH colour available control from from channel Strobe Speed channel 5 6 - 11 Master dmx 1 dimmer dmx 2 Strobe open - fast dmx 3 0-005 no function 006-015 user defined chase effect 1 016-025 user defined chase effect 2 026-035...
- Page 9 47 channel mode continued dmx 17 0 -255 UV 2 leds 3,4 dmx 18 0 -255 Red 2 leds 3,4 dmx 19 0 -255 Green 2 leds 3,4 dmx 20 0 -255 Blue 2 leds 3,4 dmx 21 0 -255 White 2 leds 3,4 dmx 22 0 -255...
- Page 10 84 channel dmx mode 84 CH dmx 1 red led 1 0 - 100% dmx 2 Green led 1 0 - 100% dmx 3 Blue led 1 0 - 100% dmx 4 White led 1 0 - 100% dmx 5 Amber led 1 0 - 100% dmx 6...
- Page 11 UK based with readily available spares and new units in the UK. This Dmx shutter was designed and manufactured in the UK by ULS Manufacturing. Our engineers have a detailed knowledge and are able to provide technical support both over the telephone, email and at our UK Headquarters.
