  • Page 2: Table Of Contents

    INDEX Pg. 3 1. Introduction Pg. 4 2. Safety Information Pg. 4 3. Specification Characteristics Pg. 5 4. Onboard Features (Nomenclature) Pg. 6 5. Mechanical Details Pg. 7 6. Installation Pg. 8 6.1 Access Point Mode Installation Pg. 8 6.1.1 Basic Connection Pg.

  • Page 3: Introduction

    1. Introduction The P WiFi™ PCB is the newest addition to the LED CV DMX decoder family for SIRS-E. This ILOTINO version of the P ™ comes in a bare PCB format. This product is intended to be embedded into ILOTINO custom fixtures and lighting control systems in which component size is critical.

  • Page 4: Safety Information

    2. Safety Information Safety Information The exposed PCB design of this product results in a major reduction in its foot print. With a slim and narrow design, this configuration is intended to be used in applications that would benefit from this feature. Some examples of applications include: fixture integration, custom control enclosures, and others.

  • Page 5: Onboard Features (Nomenclature)

    4. Onboard Features 1. I/O Connection Socket + DMX out (For P ™ PCB) ILOTINO 2. I/O wire to board quick connectors 3. Dip Switches to set the DMX line termination 4. Mounting holes for Standoffs M2.5 (metric) 5. Pairing button for WiFi connections 6.

  • Page 6: Mechanical Details

    5. Mechanical Details WiFi™ PCB Top View ILOTINO 68.00mm 15.84mm 16.00mm 22.25mm 49.50mm WiFi™ PCB Side View ILOTINO 16.25mm 3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908 WiFi™ PCB Instruction Manual Copyright © 2006-2021 SIRS Electronics Inc. All Rights Reserved ILOTINO Updated 09/2021.

  • Page 7: Installation

    6. Installation Standoffs Four 2.5M x 5mm standoffs should be used to properly mount the unit onto a smooth and level surface. It is recommended that the included factory 2.5M stand offs be used. To fasten the P WiFi™ PCB onto a surface, first screw the four ILOTINO screws in a crisscross pattern.

  • Page 8: Access Point Mode Installation

    6.1 Access Point Mode Installation 6.1.1 Basic Connection Make sure the P WiFi™ PCB and antenna are connected to the P ™ PCB. ILOTINO ILOTINO Power on the P ™ PCB board once proper wiring connections are done to eliminate ILOTINO short circuiting the board.

  • Page 9: Daisy Chain

    6.1 Access Point Mode Installation 6.1.2 Daisy Chain Make sure the P WiFi™ PCB and antenna are connected to the P ™ PCB. ILOTINO ILOTINO Connect the DMX IN/OUT wires to each of the P ™ PCB boards in a sequence, similar ILOTINO to a daisy flower ring, to each corresponding connector.

  • Page 10: Station Mode Installation

    6.2 Station Mode Installation 6.2.1 Basic Connection Make sure when connecting each P WiFi™ PCB and antenna to a P ™ PCB. ILOTINO ILOTINO Power on the P ™ PCB boards once proper wiring connections are done to eliminate ILOTINO short circuiting the boards.

  • Page 11: Daisy Chain

    6.2 Station Mode Installation (cont.) 6.2.2 Daisy Chain Make sure the P WiFi™ PCB and antenna are connected to the P ™ PCB ILOTINO ILOTINO that is used individually and another P ™ PCB that is being daisy chained. ILOTINO Connect the DMX IN/OUT wires to each of the P ™...

  • Page 12: Stand Alone Mode Installation

    6.3 Stand Alone Mode Installation 6.3.1 Basic Connection (Access Point) Make sure the P WiFi™ PCB and antenna are connected to a power source (5 Vdc). ILOTINO Properly connect the P WiFi™ PCB to a DMX Driver utilizing the DMX IN/OUT connectors. ILOTINO Power on the P WiFi™...

  • Page 13: Daisy Chain (Access Point)

    6.3 Stand Alone Mode Installation (cont.) 6.3.2 Daisy Chain (Access Point) Make sure the P WiFi™ PCB and antenna are connected to a power source (5 Vdc). ILOTINO Connect the DMX IN/OUT wires to each of the DMX Drivers in a sequence, similar to a daisy flower ring, to each corresponding connector.

  • Page 14: Basic Connection (Station)

    6.3 Stand Alone Mode Installation (cont.) 6.3.3 Basic Connection (Station) Make sure each P WiFi™ PCB and antenna are connected to a power source (5 Vdc). ILOTINO Properly connect each P WiFi™ PCB to a DMX Driver utilizing the DMX IN/OUT connectors. ILOTINO Power on the P WiFi™...

  • Page 15: Daisy Chain (Station)

    6.3 Stand Alone Mode Installation (cont.) 6.3.4 Daisy Chain (Station) Make sure the P WiFi™ PCB and antenna are connected to a power source (5 Vdc). ILOTINO Connect the DMX IN/OUT wires to each of the DMX Drivers boards in a sequence, similar to a daisy flower ring, to each corresponding connector.

  • Page 16: Wifi - Access Point Mode

    7. Wi-Fi - Access Point Mode The Access Point (default mode) is the P WiFi™ PCB acting as its own network. A cyan indicator LED turns steady ILOTINO on the P WiFi™ PCB. This allows for a complete wireless solution for a smartphone to act as a DMX controller. ILOTINO 7.1 Basic Connection 7.1 Network Connection...

  • Page 17: Wifi - Station Mode

    8. Wi-Fi - Station Mode The Station mode is when the P WiFi™ PCB connects to a near by wireless internet router. A blue indicator LED ILOTINO on the P WiFi™ PCB turns steady. This allows for a complete wireless solution for a smartphone to act as a DMX ILOTINO controller.

  • Page 18: Ip Address

    8.2 IP Address The IP addresses are an identifier assigned from the router and are required for connecting devices to access the network. On a computer or smartphone device, access the Network & Internet settings and locate the P WiFi™ PCB ILOTINO IP settings in the properties section to correctly set the Art-Net App.

  • Page 19: Default Setting

    9. Default Setting To return the P WiFi™ PCB to the default settings, press and hold the pairing button, for about 10 ILOTINO seconds, until the indicator LED turns green and has blinked once. The indicator LED will turn cyan after a few seconds to indicate the P WiFi™...

  • Page 20: Hardware And Accessories

    OEM Coax cable IPEX to RP-TNC, 15 cm 50 ohm at 2.45 Ghz 3307 West St. Rosenberg , Texas 77471 Phone: 281-324-0908 www.sirs-e.com 3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908 WiFi™ PCB Instruction Manual Copyright © 2006-2021 SIRS Electronics Inc. All Rights Reserved ILOTINO...

  • Page 21: Ul Certification

    Confirmation Letter UL CUSTOMER ALBA ELETTRONICA SRL Via L Da Vinci 3 Mogliano Veneto, 31021 Italy UL CUSTOMER FILE # E203656 CATEGORY Wiring, Printed - Component | ZPMV2 August 4, 2021 As of the above date, UL LLC confirms that ALBA ELETTRONICA SRL is the party associated with UL File # E203656 that appears in the UL Product iQ platform.
