Thank you for purchasing a DINI ARGEO product. This manual contains all the instructions for the correct installation and commissioning of the 6116EVO industrial PC. While thanking you for purchasing this product, we would like to draw your attention to some aspects of this manual. -
Page 5: Installation
Installation Installation requirements Observe the following conditions for correct installation of the industrial PC and of the load receiver: • Flat, level support surface. • Stability and absence of vibrations. • Absence of aggressive dust and vapours. • Absence of draughts. •... - Page 6 RECOMMENDED DISTANCES AND CABLE CLASSIFICATION Category I Category II Category III Category IV ≥ 100 mm ≥ 200 mm ≥ 500 mm Distance ≥ 100 mm ≥ 500 mm ≥ 500 mm Fieldbus, LAN network (PROFIBUS, Ethernet, Devicenet...). DC supply cables Shielded data cables with voltage >...
-
Page 7: Earthing Of The System
The 6116EVO is earthed through the power cable. WARNING: Check that the power supply socket to which the 6116EVO Industrial PC will be connected has an earth line. GENERAL NOTES: •... -
Page 8: Dimensional Technical Drawings
Dimensional technical drawings 6116EVO / 6116EVO-PC VESA 100 M4 x 10 mm ETHERNET USER_MAN_ENG_6116EVO... -
Page 9: 6116Evo-Dgt
6116EVO-DGT 15,5 ETHERNET USER_MAN_ENG_6116EVO... -
Page 10: Wiring Diagrams
Wiring diagrams 6116EVO USER_MAN_ENG_6116EVO... -
Page 11: 6116Evo-Dgt
6116EVO-DGT USER_MAN_ENG_6116EVO... -
Page 12: Dgx4Sp
DGX4SP RS485 PWR SUPPLY CELL #1 CELL #2 CELL #3 CELL #4 TERM Type- approved 120 Ω Internal use USER_MAN_ENG_6116EVO... -
Page 13: Dgt1
DGT1 15 14 13 12 11 10 18 17 16 RS232 LOAD CELL DISPLAY POWER RS485 Type- approved Internal use USER_MAN_ENG_6116EVO... -
Page 14: Technical Features
2 x USB 2.0 type B • 1 x LAN Internal communication ports • 2 x USB 3.0 type B (one port is occupied on the 6116EVO model) • 1 x LAN IP CLASS IP67 with valve for humidity control WORKING TEMPERATURE 0 / 60°C, 0 / 40°C for type-approved applications (6116EVO-DGT only) -
Page 15: Load Cell Installation
Load cell installation 6116EVO The transmitter has one channel (CELL#1) for 6-wire connection to load cells (using the SENSE), while for the remaining channels (CELL#2, CELL#3) only 4-wire connection is allowed. The SENSE allows you to compensate for any voltage drop on the section of the cable connecting the board to the load receiver. - Page 16 6116EVO-DGT The transmitter has a channel (CELL) for connection to 6-wire load cells (with the use of SENSE). CELL The SENSE allows you to compensate for any voltage drop on the section of the cable connecting the transmitter to the load receiver.
-
Page 17: Communication
Check the serial port to be used for communication using the Windows “Device Manager” program in the Ports (COM & LPT) submenu. For more information on communication protocols, refer to the weight transmitter manuals: • DGT1 (6116EVO-DGT) • DGX4SP (6116EVO) - Page 18 Notes This publication, part reproduced without written permission from Manufacturer. information this manual based data available time publication; Manufacturer reserves right make changes products time, without notice without incurring penalty. therefore recommend that always check updates. person responsible scale must ensure that safety...
