- Page 1 6116PRO Industrial touch screen PC with integrated scale input USE INSTRUCTIONS ENGLISH www.diniargeo.com...
- Page 3 Thank you for choosing a DINI ARGEO product. 6116PRO is the new high performance PC made in stainless steel, designed to meet the most advanced weighing needs. Intel computing power, together with Dini Argeo electronics and weighing programs, allow integrated weighing in the IoT and industrial automation world with one compact solution.
- Page 4 Turn the product on/off complying with the instructions shown in this manual. WARNING! Turning 6116PRO off by disconnecting power supply may cause data loss or corruption of the operating system image. After Windows shuts off, always wait at least 5 seconds before pressing the power button to turn off.
- Page 5 + 100 m with cable VOLTAGE aluminium bus bar. 6 x 0,5 mm 50 m with cable 2 x 0,25 mm 75 m with cable 2 x 0,5 mm 150 m with cable 2 x 1 mm 6116PRO USER_MAN_ENG_6116PRO...
-
Page 6: Earthing System
One should check and remove, if necessary, the connection between the earth and the neutral wire of the electrical installation. • If the weigh receptor is more than 10 m far from the industrial PC 6116PRO, it is recommended using the SENSE line and load cells equipped with compensation circuit (SENSE). 6116PRO... -
Page 7: Wiring Diagram
Wiring diagram 6116PRO USER_MAN_ENG_6116PRO... - Page 8 Description The PC 6116PRO allows creating specific high level applications to meet the requirements of modern companies. It is designed for those who need hardware for industrial environments. The following table describes the main parts of the industrial PC: Mod. 6116PROAF Sn 1234AA56789 110-230V AC 0.8A...
- Page 9 Dimensional technical drawing The following dimensions are shown in mm. 6116PRO USER_MAN_ENG_6116PRO...
-
Page 10: Technical Features
• Up to 3W stereo speakers. • Schuko plug. • 240 VAC power supply, 5 A maximum consumption. • 5 holes for cable gland PG9, 1 hole for cable gland PG11. • Stainless steel body AISI 304 IP67. 6116PRO USER_MAN_ENG_6116PRO... - Page 11 Ingredients database 10.000 AF05 Clients database 10.000 Tares database 10.000 Input texts Management of analog output or digital I/O modules (on request). Complete traceability of weighings and transactions, which are exportable on USB flash drive or network folders. 6116PRO USER_MAN_ENG_6116PRO...
-
Page 12: Touch Screen Calibration
Touch screen calibration Run the application "TBCALIB" from the toolbar: Insert Password: Press and hold the centre of the crosses until the circle becomes blue. 6116PRO USER_MAN_ENG_6116PRO... - Page 13 Windows, follow the procedure below: Launch file Autorun-Explorer, which can be accessed by following the file path C:\DiniArgeo\Dini Simulator\Configuration\scripts. ATTENTION! This procedure is not reversible! The software Launcher will be started by means of the link on the desktop. 6116PRO USER_MAN_ENG_6116PRO...
-
Page 14: Installation
Connect the power supply cable to port "E" and the load cell cable to port "F". Loosen the two knobs "G" for regulating the inclination of the PC. Once the right angle is found, fasten knobs "G". Press button "H" for turning on the device. 6116PRO USER_MAN_ENG_6116PRO... -
Page 15: Main Screen
They open the related application. It allows setting up the selected program as favorite. It will be displayed Favorites at power-up. It allows updating the applications, Launcher and DGT (see paragraph Update button Updating AF Firmwares on page 20). 6116PRO USER_MAN_ENG_6116PRO... - Page 16 PC. In order to add an unprotected software to the bar, just create a link to the EXE file in the folder C:\Dini Argeo\Dini Simulator\Firmwares\Tools. In order to add a software protected by a password to the bar, it is necessary to create a connection to the EXE file in the folder C:\Dini Argeo\Dini Simulator\Firmwares\ToolsPro.
- Page 17 In the industrial PC there are two virtual memories (Memory1 and Memory2) in the form of .csv file, in which all the weighings are saved on USB and SD card. They can be accessed by following the file path: C:\Dini Argeo\Shared\6116.
- Page 18 Press Printout button "C" for accessing the print functions. Press arrow "D" for accessing the second page (2/2) and select the export function "E" or "F". 6116PRO USER_MAN_ENG_6116PRO...
- Page 19 The following picture illustrates the dialog box which appears while pressing the OFF button on the structure of the industrial PC (on the lower left side). POS. DESCRIPTION It cancels the turning off operation. It restarts the device. It turns off the PC. 6116PRO USER_MAN_ENG_6116PRO...
- Page 20 In order to update the AF Firmwares loaded on the indicator, save the files provided by the reseller/supplier on a USB key and press the updating button (see "H" button in the main screen, described on page 15). On the display, a screen with a list of updated firmwares will be shown: 6116PRO USER_MAN_ENG_6116PRO...
-
Page 21: Declaration Of Conformity
The declaration of conformity can be dowloaded from the link http://www.diniargeo.it/download.aspx by inserting the serial number of the industrial PC 6116PRO. Mod. 6116PROAF Serial number Sn 1234AA56789 110-230V AC 0.8A 50-60 Hz Dini Argeo - V. Fisica, 20 - 41042 Fiorano (MO) Italy 6116PRO USER_MAN_ENG_6116PRO... - Page 22 The person responsible for the use of the weight indicator must make sure that all of the safety rules in force in the country of its use should are followed to ensure that the equipment is used in conformity with the use for which it is destined and avoid any dangerous situation for the user. The manufacturing firm declines any responsibility deriving from possible errors in weighing. 6116PRO USER_MAN_ENG_6116PRO...
- Page 24 Stamp of the authorised assistance centre HEAD OFFICE Via Della Fisica, 20 41042 Spezzano di Fiorano, Modena - Italy Tel. +39 0536 843418 - Fax +39 0536 843521 SERVICE ASSISTANCE Via Dell’Elettronica, 15 41042 Spezzano di Fiorano, Modena - Italy Tel.
