4.1.3 BPM/Volume

This menu allows assigning the BPM and two volume values. The BPM can be set to use the global BPM or preset
specific BPM.
BPM
Global : The BPM works with global BPM when the current preset is recalled.
40 - 209 : The BPM works with current value in this menu when the current preset is recalled.
Volume.A and Volume B
Each volume controller can be bypassed like other audio loops. The IA switch (Vol.A/B) must be turned
on when using the volume controller.

4.1.4 Loop Order

This menu allows changing loop order and signal routing you can make the following settings.
Change the connection order of effect loops
Create a split connection
Specify Carry Over
Symbol
Input
Input Buffer
Loop 1 and Loop2
Loop 3 ~ Loop 12 (mono-send/return)
Volume-controller A and B
There are several limitations below to change the signal routing :
The I I nput and O O utput cannot be moved.
The I I nput Buffer and L L oop 1, 2 can only be repositioned with each other.
If the signal is split from the previous, the signal cannot be split again after that.
When you set up a specific loop as the carry-over function, the volume-controller(vA or vB) must be at the
next position. When a specific loop is set to the carry-over function with the volume-controller, the line in
between is displayed with a C C ross symbol.
EFX MK-VI Audio Controller Owner's Manual
Increase/Decrease each volume value (min:-48.5dB max:+15.0dB, 0.5dB steps).
Description Symbol Description
Two Outputs
(Left/Right)
Loop 12
(mono-send/stereo-return)
