ACDB-7000AC WIRELESS DOORBELL WITH PLUGIN CHIME
EN
Read these simple guidelines. Not following them may be dangerous and faulty installation will invalidate any warranty
that may apply to this product.
COMPATIBILITY
This receiver is compatible with all Trust SmartHome
transmitters (except TMT-502 + PIR-2050).
This transmitter works with all Trust SmartHome
receivers, but only sends ON-signals.

TECHNICAL SPECIFICATIONS

• Power supply input
• RF frequency
• RF range
• Standby power consumption
• Melodies
• Volume levels
• Memory addresses
• Protection class
WIRELESS RADIO SIGNAL
• The 433.92 MHz radio signal passes through walls, windows and doors.
• Indoor range: up to 30 m. Outdoor range: up to 70 m. (optimal conditions)
• The range is strongly dependent on local conditions, such as the presence of metals. For example, the thin metal coating
in Low-emissivity (Low-E) glass has a negative impact on the range of radio signals.
• There may be restrictions on the use of this device outside the EU. If applicable, check whether this device complies with
local directives.
1
FUNCTIONALITY
Wall socket chime
Wireless push button for activating the Trust
SmartHome chime receiver.
220-240 VAC 50Hz (chime) 1x 3 Volt CR2032 lithium (push button)
433.92 MHz
Up to 30 m indoor/70 m outdoor (optimal conditions)
0.5 Watt
5
4
4
IP44
