Trust START-LINE ACD-2400 User Manual

Mains socket switch

Advertisement

Quick Links

START-LINE
SMART Home
RECEIVER ACD-2400
USER MANUAL
Version 1.0
Visit www.trustsmarthome.com
for the most recent user manuals
MAINS SOCKET SWITCH

Advertisement

loading
Need help?

Need help?

Do you have a question about the START-LINE ACD-2400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Trust START-LINE ACD-2400

  • Page 1 START-LINE SMART Home RECEIVER ACD-2400 USER MANUAL Version 1.0 Visit www.trustsmarthome.com for the most recent user manuals MAINS SOCKET SWITCH...
  • Page 2: Technical Specifications

    ACD-2400 MAINS SOCKET SWITCH COMPATIBILITY FUNCTIONALITY This receiver works with all Mains socket switch to switch lights or electronic trust smart h transmitters. devices on/off up to 2400 Watt. TECHNICAL SPECIFICATIONS Power supply input 220-240 VAC 50 Hz Maximum load...
  • Page 3: Maximum Load

    LIFE-SUPPORT detergents. Never use ome products for life- trust smart h support systems or other applications in which HANDLING equipment malfunctions can have life-threatening Do not drop, knock, or shake the device. Rough consequences.
  • Page 4 ACD-2400 MAINS SOCKET SWITCH 1 sec. 1. Connect lamp/device and place the 2a. Assign transmitter code main socket switch Press the learn-button on the receiver for 1 second. The learn-mode will be active for 15 First check if the lamp or device is turned seconds, during which the LED-indicator will on.
  • Page 5 ACD-2400 MAINS SOCKET SWITCH The receiver will switch on/off 2 times to con- Send an ON-signal with any trust smart h firm the code has been received. The receiver transmitter while the learn-mode is active, to can store up to 6 different transmitter codes assign the code to the receiver’s memory.
  • Page 6 ACD-2400 MAINS SOCKET SWITCH 3. Manual operation with a transmitter 1. Send an ON-signal to switch the receiver on. 2. Send an OFF-signal to put the receiver in stand-by.
  • Page 7 1. Press the learn-button for 1 second. The learn-mode will be active for 15 seconds, during which the LED-indicator will blink slowly. 2. While the learn-mode is active, send an OFF-signal of a specific transmitter trust smart h to delete that code. 3. The receiver will switch on/off 2 times to confirm code deletion.
  • Page 8 ACD-2400 MAINS SOCKET SWITCH 7 sec. 1 sec. Full memory delete 1. Press and hold the learn-button of the receiver (approx. 7 sec.) untill the LED-indicator starts blinking fast. The delete mode will be active for 15 seconds. 2. Press the learn-button again for 1 second while the delete mode is active. 3.
  • Page 9 ACD-2400 MAINS SOCKET SWITCH Trust International B.V. declares that this product is in compliance with the essential requirements and other relevant provisions WEEE: If possible, dispose of this product at a recycling center. Do not dispose of this product with the household waste.
  • Page 10 ACD-2400 MAINS SOCKET SWITCH Declaration of conformity Trust International B.V. declares that the product: trust smart h model: ACD-2400 MAINS SOCKET SWITCH item number: 75002 intended use: indoor is in compliance with the essential requirements and other relevant provisions of the following directives: EMC Directive, Low Voltage Directive and R&TTE Directive.
