modway MOD-6209 Assembly Instructions page 2

MOD-6209
HARDWARE HEADBOARD
1 JCBB BOLT M8 x 60mm
M8 FLAT WASHER
2
M5 ALLEN KEY
3
STEP 1
1.1 Align pre-drilled support stand holes over the pre-drilled headboard holes according to your
desired headboard height
1.2 Secure each support stand by using 2x JCBB Bolt [1] and 2x M8 Flat Washer [2].
Tighten with supplied Allen Key [3].
Repeat the same procedure to secure the other side.
Note: Hardware may loosen over time.
Periodically check that all connections are tight.
A
Customer Service 609-256-9000 www.modway.com
HARDWARE BED FRAME
4 PCS 4
4 PCS
5
1 PC
6
7
8
9
B
JCBB BOLT M6 x 60mm
4 PCS
JCBB BOLT M6 x 35mm
4 PCS
M6 FLAT WASHER
8 PCS
M6 SPRING WASHER
4 PCS
M6 HEX NUT
4 PCS
M4 ALLEN KEY 1 PC
3
1
2
02 of 03
