- Page 1 5022-H DISC BRAKE HYDRAULIC APPLIED VERSION Owner’s Operation, Installation & Maintenance Manual KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
-
Page 2: Table Of Contents
Preventative Maintenance ..................17 Inspection ........................17 5.2.1 Pad Wear ........................ 17 5.2.2 Seals ........................17 5.2.3 Pin Wear ......................... 18 5.2.4 Brake Disc ....................... 18 Service ......................... 18 5.3.1 Lubrication ......................18 KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) - Page 3 5.3.2 Stroke Adjustment ....................18 5.3.3 Brake Linings ......................19 Recommended Spares....................20 Warranty ........................21 Appendix A: Technical Drawings ................... 22 Appendix B: Parts List Drawings ................... 24 KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
-
Page 4: Introduction
NTRODUCTION ONTACT NFORMATION Kobelt Manufacturing Co LTD. 8238 129TH Street Surrey, British Columbia Canada, V3W 0A6 Sales Tel: 604-572-3935 Fax: 604-590-8313 Email: sales@kobelt.com ebsite: www.kobelt.com For further instructions, please contact our distributors or visit our website. 1.2 S AFETY NFORMATION 1.2.1 Safety Alerts... -
Page 5: Safety Instructions
Brakes contain numerous pinch points which can cause serious injury. Ensure all power sources are locked out prior to performing work. High Pressure Fluids: Kobelt lever brakes use high pressure hydraulics. Ensure all pressure is exhausted and the pressure source locked out prior to performing work. Hot Surfaces: Disc brakes are capable of making the surfaces of the brake disc dangerously hot when burnishing or during braking events. -
Page 6: Product Description
The diagram below shows a typical Kobelt caliper brake with all the major components identified. All of the Kobelt caliper brakes can be fitted with either air applied, hydraulic applied, spring applied with air released or spring applied with hydraulic released actuators depending on the required service. - Page 7 C and manufactured to required specifications. 2) Requires a minimum 4.34 in [110 mm] wide face Technical data and specifications are also available from our datasheet posted on www.kobelt.com the technical drawings in Appendix A. KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
-
Page 8: Model Code Key
1.5 M ODEL KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) -
Page 9: Installation
International tolerance class. Allowable run out is proportional disc O.D. Parking brakes and emergency brakes with stopping times of 10 seconds or less are considered light duty. Ventilated discs are exempted from this requirement KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) - Page 10 The cooling air pumped through the disc must be exhausted away from the outer diameter of the disc to allow fresh, cool air to enter the inner vent opening of the disc. KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
-
Page 11: Caliper Brakes
All piping must be cleaned prior to connection to the actuators. Welded carbon steel piping must be pickled to remove the scale produced by welding. The connections to the brake actuators must be made by hoses of suitable rating to accommodate the movement of the brake levers. KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) - Page 12 The brake actuators are equipped with different sizes of pressure ports. Consult the technical drawing of the relevant model code for the specific port data. Tighten the port fitting to 15 ft- lbs [20 Nm]. Threads of stainless steel fittings must be lubricated before installing. KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
-
Page 13: Commissioning
The temperature of the disc surface must be monitored during the burnishing process and kept between 250 F (120 C) and 500 F (260 C). If the upper temperature is reached, pause the burnishing process until the disc is cooled to the lower limit. KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) -
Page 14: Torque Test
Before putting equipment into service, confirm that full rated braking torque has been achieved through load testing or a torque test against the drive motors. If full brake torque has not been achieved, continue burnishing. KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) -
Page 15: Operation
4.1.1 Pressure Supply Hydraulic versions of the Kobelt lever disc brakes require up to 1000 psi of pressure to operate. The pressure supply system must supply a hydraulic oil appropriate for the service conditions. Consult the table below for approved oils. -
Page 16: Pressure
Nominal OD Max. Speed Number inch 2” x 4” Series Standard Balanced 2-4-18 1450 3070 2-4-20 1260 2750 2-4-25 2200 2-4-30 1800 2-4-35 1550 2-4-40 1016 1350 2-4-45 1143 1200 2-4-50 1270 1070 KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) -
Page 17: Maintenance
The actuator seals should be inspected on a periodic basis. For air applied brakes apply air pressure to the actuators and listen for any hissing sound that would indicate a torn or ruptured diaphragm. KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) -
Page 18: Pin Wear
5.3 S ERVICE 5.3.1 Lubrication All Kobelt calipers, during assembly, are pre-greased on the shoe pin and saddle pin with a Lithium based NLGI 2 grease. These pins must be re-greased no less than once annually. 5.3.2 Stroke Adjustment Follow the procedure below to adjust the brake shoe running clearance back within specifications. -
Page 19: Brake Linings
4. Tighten screws ‘B’ When reinstalling the shoes and pivot blocks reinstall the shoe pin first to align the pivot blocks before tightening screws ‘C’. Tighten screws ‘C’ to 200 in-lbs [ 22.7 Nm]. KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) -
Page 20: Recommended Spares
ECOMMENDED PARES The spare parts kept on hand will depend on the severity of the service. As a minimum Kobelt recommends keeping the following parts for each brake in service: 1. One Lined set of brake shoes 2. One set of brake pads with rivets 3. -
Page 21: Warranty
If any part is found to be defective, Kobelt will replace said part FOB the Kobelt factory provided that any such defective part is returned by the Buyer with freight and applicable forwarding charges prepaid by the Buyer. -
Page 22: Appendix A: Technical Drawings
A: T PPENDIX ECHNICAL RAWINGS KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) - Page 23 KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
-
Page 24: Appendix B: Parts List Drawings
B: P PPENDIX ARTS RAWINGS 5022-H KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) - Page 25 SCREW, SKT HD CAP, 3/8-16 UNC X 1, SS 1002-1112 SCREW, SKT HD, 5/16-18 X 3/4, 18-8 6112-0107 CLEVIS PIN, 6112-H ACTUATOR 1026-0312 COTTER PIN 3/32 X 3/4 SS 1202-0009 SPRING, EXTENSION, 0.83 OD X .080 WIRE, AISI 302, 14 TURNS KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
- Page 26 5022-HW KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
- Page 27 SCREW, SKT HD CAP, 3/8-16 UNC X 1, SS 6112-0107 CLEVIS PIN, 6112-H ACTUATOR 1026-0312 COTTER PIN 3/32 X 3/4 SS 1202-0009 SPRING, EXTENSION, 0.83 OD X .080 WIRE, AISI 302, 14 TURNS 1002-1112 SCREW, SKT HD, 5/16-18 X 3/4, 18-8 KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
- Page 28 PISTON, 6112-H ACTUATOR 1016-0804 SET SCREW 10-24 X 1/4, SS 1002-0808 SCREW, SKT HD CAP, #10 UNC x 1/2 LG, SS 6212-0005-S CLEVIS, SHORT, 5/8 UNC X 3/8 PIN 6112-H-RK HYDRAULIC ACTUATOR, 1200 LBS KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A)
- Page 29 5022-LS ITEM QTY. PART NUMBER DESCRIPTION 5022-0007 BRAKE PAD; 1/2IN K5 5022-0005 BRAKE SHOE 1033-1007 RIVET, 1/4 X 7/16 (10-7), BRASS KOBELT MANUFACTURING CO. LTD MNL-5022-H.docx (rev A) Heiko Digitally signed by Heiko Epkens Epkens Date: 2021.10.25 09:37:14 -07'00'...
