- Page 1 POLERMO Projection Clock with Motion Alert Model: RMR939PA / MSR939A USER MANUAL RMR939PA English Cover R7 10/20/04, 10:34 AM...
-
Page 2: Table Of Contents
POLERMO Projection Clock Clock / Calendar ............. 13 Clock / Calendar Display ........13 with Motion Alert Setting the Clock / Calendar ........ 14 Model: RMR939PA / MSR939A Backlight ..............14 USER MANUAL Temperature ............14 Alarm ............... Alarm Display ............CONTENTS Setting the Alarm(s) .......... -
Page 3: Introduction
Notices ..............23 INTRODUCTION Statement of Responsibility ......... 23 Thank you for selecting the Oregon Scientific About Oregon Scientific ........23 POLERMO Projection Clock with Motion Alert. This FCC Statement ............24 device is designed to give you many years of reliable service, including the following conveniences: Declaration of Conformity ........ -
Page 4: Product Overview
PRODUCT OVERVIEW FRONT VIEW 1. SOUND / SLEEP button • Press to turn the soothing sound ON. • Press to wrap around the sleep timer setting as follows: 0 minutes. • Press and hold for 2 seconds to choose 1 of 6 soothing sounds. - Page 5 • Press and hold for 2 seconds to enter: - Motion Sensor Code. - Motion Alarm Setting Mode for motion alarm period and alarm type. 6. Projector Projects time and alarm status. 7. CLOCK button • Press to toggle between the following display modes: - Clock with seconds and calendar.
-
Page 6: Back View
BACK VIEW 1. Projector FOCUS knob • Twist to focus the projected image. 2. Projector IMAGE ROTATION knob • Twist to get the best viewing angle of the projected image. 3. PROJECTION ON switch • Slide to ON for continuous image projection when the AC power is connected. -
Page 7: Lcd Display
LCD DISPLAY 1. SOUND • Appears when the sleep function is activated. 2. Battery Low icon • Appears when the clock batteries are low or, no batteries are installed and only the AC adaptor is connected. 3. Time • HH / MM, 12- / 24-Hour, AM / PM. 4. - Page 8 10. MIN • Appears when the sleep function is activated. 11. Time Zone Hour Offset / Day of the Week • Offsets the atomic clock time setting when you are in a different time zone (+ / -23 hours). • Name of day available in 1 of 5 languages. 12.
-
Page 10: Remote Motion Sensor (Msr939A) - Back View
REMOTE MOTION SENSOR (MSR939A) - BACK VIEW 1. Wall Mount 2. Battery Compartment (cover on) • Uses 3 x UM-3 / AA 1.5V batteries. 3. CHANNEL 1 / 2 • Slide to select either Channel 1 or Channel 2. 4. CODE switch •... -
Page 11: Safety And Care
• Keep your product away from hot, humid conditions SAFETY AND CARE or strong sunlight. SAFETY PRECAUTIONS • Every effort has been made to ensure the highest standards of reliability for your clock with remote Please observe the following safety precautions when motion sensor. -
Page 12: Batteries
To install the clock batteries: BATTERIES The clock uses: • 4 x UM-3 / AA 1.5V batteries. The motion sensor uses: • 3 x UM-3 / AA 1.5V batteries. The optional wake-up vibration alarm VR101A (not included in the package) uses: •... -
Page 14: Turning The Atomic Clock Signal On / Off
To turn the atomic clock signal reception OFF: NOTE For best results, place the clock away from metal or electrical objects, and near a window with a clear view • Press and hold the button for 2 seconds. to the sky. •... -
Page 15: Setting The Clock / Calendar
6. Press CLOCK ALARM or MOTION ALARM to exit SETTING THE CLOCK / CALENDAR the Clock Setting Mode. Before you can manually set the clock and calendar, you must specify the current time zone you live in and You can select 1 of the 5 following languages: the time format (12- or 24-hour) as follows: SYMBOL LANGUAGE... -
Page 16: Alarm
ACTIVATING / DEACTIVATING THE ALARM(S) ALARM • Press the CLOCK ALARM button to toggle between ALARM DISPLAY alarm 1 and alarm 2 ON / OFF. The melody and vibration alarm icons indicate the daily • When the melody or vibration alarm icons appear alarm settings. -
Page 17: Motion Alarm
NOTE If no button is pressed, the alarm will SETTING THE MOTION ALARM automatically silence after 2 minutes. It will then sound The motion alarm has a security / monitoring function, again in 24 hours. whereby when the motion sensor detects movement, it sets off the clock alarm for 5 minutes and the backlight will turn on for 10 seconds. -
Page 18: Turning The Motion Alarm Off
Press CLOCK or CLOCK ALARM at any time to exit the Motion Alarm Setting Mode. TURNING THE MOTION ALARM OFF Press any button on the clock to turn the motion alarm off. It will sound again when the remote motion sensor unit detects a motion again. -
Page 19: Projection Unit
NOTE You can also press the SNOOZE / LIGHT button to project the time and alarm status for 5 seconds. MOTION SENSOR (MSR939A) The motion sensor has a security / monitoring function. It can set off your motion alarm on the clock for 5 minutes and turn the backlight on for 10 seconds when it detects movement. -
Page 20: Wake-Up Vibration Alarm - Vr101A (Optional)
5. Press the RESET button. Close the motion sensor You may need to experiment with various locations to battery compartment. get the best results. 6. Secure the sensor in the desired location using the wall mount or table stand. WAKE-UP VIBRATION ALARM - VR101A 7. -
Page 21: Warnings
PCs, This product is designed to give you years of service if correctly signal phones, and other handled properly. Oregon Scientific will not be set. reception. electronic equipment responsible for any deviations in the usage of the device... -
Page 24: Notices
STATEMENT OF RESPONSIBILITY Visit our website (www.oregonscientific.com) to learn more about Oregon Scientific products such as digital Oregon Scientific will not be held liable for any bodily cameras; MP3 players; children's electronic learning injury, death, property damages, or any other claims of products and games;... -
Page 25: Fcc Statement
• Reorient or relocate the receiving antenna. FCC STATEMENT • Increase the separation between the equipment and This device complies with Part 15 of the FCC Rules. receiver. Operation is subject to the following two conditions: • Connect the equipment into an outlet on a circuit (1) This device may not cause harmful interference, and different from that to which the receiver is connected. -
Page 26: Declaration Of Conformity
2. This device must accept any interference received, the warranty card for this product) for all inquiries instead. including interference that may cause undesired operation. Name: Oregon Scientific, Inc. Address: 19861 SW 95th Place, Tualatin, Oregon 97062 USA Telephone No.: 1-800-853-8883 Fax No.:... - Page 27 © 2004 Oregon Scientific. All rights reserved. P/N: 000-000000-000 RMR939PA English Back R7 10/20/04, 10:34 AM...
