N1-2400 Quick Start Guide
Important safety instructions
Please read the following instructions carefully.
1
To clean the N1-2400 screen:
•
Turn off the N1-2400 and unplug the power cord.
•
Spray a non-solvent cleaning solution onto a rag and clean the screen gently.
2
Do not place the N1-2400 near a window. Exposing the monitor to rain, moisture or sunlight can severely
damage it.
3
Do not apply pressure to the LCD screen. Excessive pressure may cause permanent damage to the
display.
4
Do not remove the cover or attempt to service this unit yourself. An authorized technician should perform
servicing of any nature.
5
Store the N1-2400 in a room with a temperature of -20° to 60° C (-4° to140° F). Storing the N1-2400
outside this range may result in permanent damage.
6
Immediately unplug your monitor and call an authorized technician if any of the following circumstances
occur:
•
Monitor-to-PC signal cable is frayed or damaged.
•
Liquid spills onto the N1-2400 or the monitor is exposed to rain.
•
The N1-2400 or case is damaged.
Package contents
N1-2400
Power cord and adapter
*
: Optional
Connecting your monitor to a computer
1
Turn off your computer and unplug your computer's power cord.
2
Connect the HDMI cable to the HDMI input socket of the monitor, and the HDMI output socket of the
graphics card on the computer.
3
Optional: Connect the micro USB port of the N1-2400 and the USB-out port on the computer with the USB
cable.
4
Plug the N1-2400's power adapter into the power port at the back of the monitor.
5
Plug the power cords of your computer and your monitor into a nearby electrical outlet.
6
Press the power button and the N1-2400 turns on.
7
To switch to HDMI display, press the function keys to select or adjust an option.
Please refer to the User Guide for information about setting up your N1-2400.
Turning on for the first time
You will be asked some questions before you can use your monitor as a N1-2400.
To set up or access a Google account, connect your N1-2400 to an Ethernet or Wi-Fi access point.
External controls
Turns the display on/off. White indicates power on.
Power button
When using the HDMI input, press the left function button to select or adjust an
option.
To change the volume, press the right function button to view the OSD. Slide the volume bar left or right.
* HDMI cable
* Keyboard
* Mini USB
(with MHL
and Mouse
cable
support)
1
Quick start
* User
guide and
manual
setup guide
