Pressure Display
Power On/Off
(Press and Hold)
Low Battery
Indicator
Active Port
Indicators
Battery
Charger
Input
Leg 1 Port
Leg 2 Port
Please call 800-994-0464 with any questions.
TP248 REV00
Quick Start Guide
Apply the DVT calf wrap(s)
1
to your leg(s) as shown.
AUX On
and Pressure Set
Fasten
Battery
Charging
Indicator
Red = Charging
Green = Full Charge
AUX Port
Turn the machine on by pressing
3
and holding the POWER ON/OFF
button until the lights are illuminated
and the display reads "ON." This
will activate both ports 1 and 2.
Press and Hold
Plug the hose(s) into the ports by
2
depressing the metal thumb tabs
on the port at the bottom of the
machine. Plug the AC adapter into
the BATTERY CHARGER INPUT.
Air Tube
(Back of Calf)
Power Adapter
Leg 1
Leg 2
IF YOU HAVE BEEN PRESCRIBED A
4
JOINT WRAP: Press "AUX ON" to
activate the AUX port. Press and
release "AUX ON" to toggle through
pressure settings.
Press to activate
AUX port (if using)
AUX Port
