- Page 1 SediPoint – sedimentation shaft ® Installation and maintenance manual Last modified: January 2020 DRAINAGE SYSTEMS ELECTRICAL SYSTEMS BUILDING TECHNOLOGY INDUSTRIAL PRODUCTS...
-
Page 2: Safety Instructions
CAUTION always consider the entire system. reasons, use original spare parts and Avoid work during rain. accessories approved by the manufacturer. The use of other parts may void the liability for any consequences arising therefrom. FRÄNKISCHE | IM MM SediPoint... -
Page 3: Table Of Contents
4.10 Filling the system 5. Cleaning 15 – 17 5.1 General cleaning information 5.2 Cleaning 5.3 Special case – removing the sediment collector 5.4 Optional connection set 5.5 Special case – light liquid spills 6. Contact FRÄNKISCHE | IM MM SediPoint... -
Page 4: Sedipoint At A Glance
2. SediPoint at a glance SediPoint with optional connection set Optional: connection set Optional: connection set 1 SediPoint 4 Inlet Sediment collector with 5 Outlet flow separator 6 Mud chamber Immersion pipe 7 Operating pipe with telescopic rod 3 Integrated bypass incl. -
Page 5: System Description
3. System description 3.1 Application SediPoint is a shaft system for the treat- environment and downstream ment of polluted stormwater runoff stormwater management structures. from built-up areas to protect the 3.2 System description Lightweight and durable PP shaft DN Optional accessories: 600, black outside, yellow inside, for optimum inspectability. -
Page 6: System Description
3.5 Collecting volumes Light liquid * Mud chamber Permanent water collecting volume level volume System collecting volume [litres] SediPoint 0.15 0.45 * In case of spills in dry weather FRÄNKISCHE | IM MM SediPoint... -
Page 7: Transport And Construction Site Storage
Connection set, consisting of crosspiece, The relevant safety provisions of the coupling KG 315, building industry apply. bend segment, coupling KG 200, extension pipe DN 250 and class D shaft cover CW 300 FRÄNKISCHE | IM MM SediPoint... -
Page 8: Excavating Pit And Creating Bearing
The base shaft is delivered as individual sediment collector and cone form a shaft body. Sealing ring, operating pipe, packaging unit and are separated at first. Packaging unit Components included Sealing ring Sediment collector Cone Operating pipe FRÄNKISCHE | IM MM SediPoint... - Page 9 Close by turning clockwise. Adjust the telescopic rod of the operating For better accessibility, position the pipe, if required, with extension for large handle directly under the mud bucket. shaft depths. FRÄNKISCHE | IM MM SediPoint...
-
Page 10: Installing The Base Shaft
Mount cone with sealing ring on base shaft into the second corrugation trough, use lubricant. SediPoint with extension pipe and class D cover min. inlet depth of pipe invert of 1.57 m below ground level max. inlet depth of pipe invert of 2.50 m below ground level Mount cone with sealing ring on base shaft into the second corrugation trough, use lubricant. - Page 11 Min. outlet height 1.02 m Max. outlet height 2.50 m Cone - 27 cm shortened Cone unshortened * ... 1x support ring h = 8 cm, 2x support ring h = 10 cm, incl. 1 cm mortar joint each FRÄNKISCHE | IM MM SediPoint...
-
Page 12: Embedding The Pipe
CW 610, with ventilation Cl. D shaft cover openings and dirt trap acc. to CW 300 DIN 1221 (to be supplied on site) Inlet SediPoint connection set Inlet Example SediPoint outlet height 1.02 – 1.57 FRÄNKISCHE | IM MM SediPoint... -
Page 13: Tests Before Backfilling And Impermeability Test
Create the bearing from Install shaft covers according to DIN EN compacted bearing layer material (EV2 124, CW 610, with ventilation openings, module ≥ 100 MN/m²) or in-situ concrete FRÄNKISCHE | IM MM SediPoint... -
Page 14: Filling The System
4.10 Filling the system After the work has been completed, the retention of floatables and light liquids system must be refilled with water up to through the immersion wall. the outlet. This is required to ensure the FRÄNKISCHE | IM MM SediPoint... -
Page 15: General Cleaning Information
Snap the tip of the bail of the sediment collector in the shaft wall to View of the shaft with operating pipe avoid uplift of the collector in the shaft. After removing the operating pipe FRÄNKISCHE | IM MM SediPoint... -
Page 16: Cleaning
Insert the operating pipe. Close the bayonet nut connector by turning it clockwise. The bayonet nut connector is closed if the handles point towards inlet and outlet. Refill the shaft. Insert the dirt trap. Close the cover. FRÄNKISCHE | IM MM SediPoint... -
Page 17: Special Case - Removing The Sediment Collector
When re-inserting the sediment collector, SediPoint. If, in exceptional cases, above removed using a winch or tripod. the lock pins of the shaft bottom must snap into the recesses of the collector base. - Page 18 In addition, we do not assume any liability or responsibility for system characteristics and functionalities when third-party products or accessories are used in combination with FRÄNKISCHE systems. We only assume liability if original FRÄNKISCHE products are used. For use in other countries than Germany, country-specific standards and regulations must also be observed. FRÄNKISCHE | IM MM SediPoint...
- Page 19 +49 9525 88-8824 stefan.weiss@fraenkische.de klaus.lichtscheidel@fraenkische.de European Sales Jennifer Gernert Carolin Rausch +49 9525 88-2569 +49 9525 88-2229 jennifer.gernert@fraenkische.de carolin.rausch@fraenkische.de Julia Möller Viktoria Majewski +49 9525 88-2394 +49 9525 88-2103 julia.moeller@fraenkische.de viktoria.majewski@fraenkische.de Fax +49 9525 88-2522 FRÄNKISCHE | IM MM SediPoint...
- Page 20 Rooted in Königsberg – globally successful! Our facilities in Europe: Königsberg, Germany (headquarters) Bückeburg, Germany Schwarzheide, Germany Okříšky, Czech Republic St.-Leonards-on-Sea, Great Britain Our facilities in Africa: Moscow, Russia Ben Arous, Tunisia Yeles/Toledo, Spain Casablanca, Morocco Torcy-le-Grand, France Our facilities in Asia: Mönchaltorf, Switzerland Our facilities in North America and Mexico: Milan, Italy...
