Features:
closed position
ATD-70450 ATD-70451
31" 4-Drawer Deluxe Service Cart
Owner's Manual
Made in China to ATD Tools, Inc. Specifications
Visit us at www.atdtools.com
Dimensions:
WIDTH
Overall:
31"
Top Compartment:
29.6"
(2) Small Drawer:
11.6"
(1) Middle Drawer:
25.4"
(1) Big Drawer:
25.4"
(1) Bottom Tray:
30"
DEPTH
HEIGHT
CAPACITY
20.4"
40.2"
500 lbs.
18.8"
5.9"
100 lbs.
20.5"
2.8"
40 lbs. each
17.2"
2.8"
100 lbs.
17.2"
6"
100 lbs.
19.2"
3"
120 lbs.
ATD70450_ATD70451_rev_0719
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ATD Tools ATD-70450
Summary of Contents for ATD Tools ATD-70450
- Page 1 40 lbs. each (1) Middle Drawer: 25.4" 17.2" 2.8" 100 lbs. (1) Big Drawer: 25.4" 17.2" 6" 100 lbs. (1) Bottom Tray: 30" 19.2" 3" 120 lbs. Made in China to ATD Tools, Inc. Specifications ATD70450_ATD70451_rev_0719 Visit us at www.atdtools.com...
- Page 2 READ AND UNDERSTAND THIS MANUAL BEFORE USING THIS PRODUCT Do not open more than 1 drawer at 1 time as the cart can become unstable and turn over causing property damage and/or personal injury. Heed the warnings on all labels. ASSEMBLY INSTRUCTIONS Figure 1 of the pry bar holder is placed against the legs.
- Page 3 4) Attach the leg/bumper assembly to each side of the cart, aligning the cutout section of the plastic bumper so the bolts fit the top of the cart. Leave bolts loose to allow for attachment of the tray in Figure 3 Figure 3 5) Attach the leg/bumper assembly to the bottom tray.
- Page 4 6) Once all bolts have been inserted and are aligned, fully tighten all bolts. 7) Attach the push handle – it can be mounted on either side of the cart. (See figure 5). Note that in the shorter bolts are inserted into the other side of the cart to fill the handle mounting holes on that side. Figure 5 Figure 5 9) Your ATD service cart is now ready for use.
- Page 5 NOTE:...
-
Page 6: Replacement Parts
REPLACEMENT PARTS Not all components of the cart are replacement items, but are illustrated as a convenient reference for position in the assembly sequence. ordering parts, give model number, part number and description. Call your distributor for current pricing: ITEM# ORDERING PART# PART DESCRIPTION ITEM# ORDERING PART# PART DESCRIPTION PRT70450 01 TOP LID GREEN*... -
Page 7: Year Limited Warranty
WARRANTY 1 YEAR LIMITED WARRANTY THIS WARRANTY AND CONFIRMED RECEIPT(S) SHOULD BE RETAINED BY THE CUSTOMER AT ALL TIMES _______________________________________ ________________________________________ INVOICE/RECE To access the benefits of this warranty, contact your supplier, or point of sale directly. You may be advised to return the product under warranty, freight prepaid, to your supplier for warranty determination.
