ATD Tools ATD-70400 Owner's Manual & Operating Instructions

31” 7 drawer flip-top service cart

Advertisement

Available languages

Available languages

ATD-70400 / ATD-70401 / ATD-70402
OWNER'S MANUAL
& OPERATING INSTRUCTIONS
MANUEL DU PROPRIÉTAIRE
MODE D'EMPLOI
GUÍA DE UTILIZACIÓN Y
DIRECTIVAS DE
FUNCIONAMIENTO
CHARIOT DE SERVICE À COUVERCLE RABATTABLE À 7 TIROIRS DE
DE SERVICIO DE TAPA ABATIBLE DE 7 CAJONES DE
WARNING:
1. Close and lock drawers before moving.
2. Do not stand on the tool service cart. You may fall which may cause personal injury.
3. Do not climb on, in or around. Keep away from children.
4. Unit has a maximum load capacity of 88 lbs. (40 kg) per drawer. Do not overload.
5. Do not pull the tool service cart, push to move.
6. Do not step in the drawers. You may fall which may cause personal injury.
7. Read all instructions and safety tips before using this product.
AVERTISSEMENT :
1. Fermer et verrouiller les tiroirs avant de déplacer l'unité.
2. Ne pas monter sur le produit. Une chute pourrait survenir et causer des blessures.
3. Ne pas grimper sur, dans ou autour de l'unité et garder les enfants éloignés.
4. L'unité a une charge maximale de 40 kg (88 lbs.) par tiroir. Ne pas les surcharger.
5. Ne pas tirer. Pousser pour déplacer.
6. Ne pas monter dans les tiroirs. Une chute pourrait survenir et causer des blessures.
7. Lire toutes les directives et conseils de sécurité avant d'utiliser ce produit.
ADVERTENCIA :
1. Cierre y eche con llave los cajones antes de mover.
2. No se pare sobre el producto. Una caída podría ocurrir y causar lesiones personales.
3. Evitar de subir sobre ó alrededor del banco. Guardar alejado de los niños.
4. La unidad tiene una capacidad de peso máximo de 88 libras (40 kg) libras por
cajón. Evitar de sobrecargar. Evitar de empujar ó tirar para mover.
5. No tirar, empujar para mover.
6. Evitar de trepar en los cajones. Una caída podría ocurrir y podría causar lesiones.
7. Este artículo no es un juguete. No está destinado al uso de los niños.
WARNING: This product contains chemicals, including lead, known to the State of California to cause cancer,
3 " 7 DRAWER FLIP-TOP SERVICE CART
MODEL / MODÈLE / MODELO:
ATD-70400 / ATD-70401 / ATD-70402
birth defects or other reproductive harm. Wash hands after handling.
Made in China to ATD Tools, Inc. Specifications
Visit us at www.atdtools.com
CMCARRO
CM
(Rev 0217)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATD-70400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ATD Tools ATD-70400

  • Page 1: Operating Instructions

    WARNING: This product contains chemicals, including lead, known to the State of California to cause cancer, birth defects or other reproductive harm. Wash hands after handling. Made in China to ATD Tools, Inc. Specifications (Rev 0217) Visit us at www.atdtools.com...
  • Page 2 THANK YOU FOR PURCHASING AN ATD TOOLS SERVICE CART. WE APPRECIATE YOUR BUSINESS. Before operating your tool service cart, please read the following carefully: KEEP INSTRUCTION MANUAL IN A SAFE PLACE UPON OPENING YOUR NEW TOOL SERVICE CART. THE KEY CODE TO YOUR HMC SECURE PREMIUM TUBULAR LOCK CAN BE FOUND ON THE BACK OF THIS MANUAL.
  • Page 3: Maintenance

    MAINTENANCE Ball-Bearing Slides Note: Unload drawer prior to drawer removal. er prio Never overload drawers. To remove drawers and slides, pull drawer all the way out, depress the black drawer release levers on each slide. For ball-bearing glides, there is one black lever per slide. One black lever will be pushed down and the other will be pushed up for drawer removal.
  • Page 4 MODE D’EMPLOI DE VOTRE UNITÉ COMPOSER LE Pour obtenir des pièces de rechange ou de l'assistance en garantie, veuillez contacter directement votre fournisseur ATD. DES PIÈCES. 2. Ouvrir la boîte et étendre les pièces dans un endroit dégagé. 3. Se familiariser avec toutes les pièces et les comparer à l’illustration ci-dessous pour s’assurer qu’il n’en manque aucune.
  • Page 5: Entretien

    ENTRETIEN Glissières à roulement à billes Remarque : vider le tiroir avant de le retirer. Ne jamais surcharger les tiroirs. Pour retirer les tiroirs et les glissières, ouvrir complètement le tiroir. Dégager les leviers noirs de chaque côté; sur les glissières à roule- ment à...
  • Page 6 GRACIAS POR SU COMPRA DE UNA UNIDAD ATD TOOLS. APRECIAMOS SU CLIENTELA. Para piezas de repuesto o asistencia de garantía, póngase en contacto con su proveedor ATD directamente. 1. Antes de montar las piezas, averiguar la cantidad de piezas in acuerdo con la lista de piezas.
  • Page 7: Mantenimiento

    MANTENIMIENTO Correderas a rodam Nota: Vaciar el cajón antes de moverlo. Nunca sobrecargar los cajones. Para retirar los cajones y las correderas abrir completamente el cajón, soltar loa palancas negras en cada lado Sobre las correderas a roda- miento hay una palanca negra en cada lado. Una palanca será empu- jada hacia abajo en un lado y hacia arriba al otro lado para poder retirar para el cajón.
  • Page 8 UNA GARANTÍA LIMITADA DE 5 AÑOS LLAME POR FAVOR SU PUNTO DE COMPRA PARA LA SATISFACCIÓN DE LA GARANTÍA O PARA LAS CUESTIONES DE REEMPLAZO DE LAS PARTES. ATD Tools, Inc. 160 Enterprise Drive Wentzville, MO 63385 Visit us at www.atdtools.com...
  • Page 9 ATD-70400 / ATD-70401 / ATD-70402 ITEM# ORDERING PART# PART DESCRIPTION PRT70400-01 LOCK WITH KEYS (CR0001090-B) PRT70400-02 LOCKING CASTER (1) (AC436) PRT70400-03 NON-LOCKING CASTER (1) (AC435) PRT70400-04 PUSH HANDLE (AC335) PRT70400-05 HARDWARE SET PRT70400-06 LIFT SUPPORT (1) (AC507) DRAWER SLIDES (PAIR)

This manual is also suitable for:

Atd-70401Atd-70402

Table of Contents
