MPSTP2E
B
Any change or modification of the product is forbidden if not expressly
0. DESCRIPTION
MPSTP2E
is a radio transmitter used with radio receivers of the Multipass and Roll series. It has two
B
pushbuttons being capable to activate two different output channels on a radio receiver working with the same
code and the same operating frequency.
It works on 433.920 MHz frequency regulated by a SAW oscillator. It is provided with an integral antenna. It is not
possible to transmit continously with MPSTP2E
1. APPLICATIONS
It can be used in remote control applications as door opener and in control access applications.
2. TECHNICAL FEATURES
Transmission frequency
Type of code
No. Of channels
Power supply
Power consumption
Duration of transmission
Signalling devices
ENGLISH
CAUTION FOR THE USER
approved by the manufacturer
.
B
433.92 MHz (radio section) – 125 kHz (transponder section)
rolling code
2 (radio) + 1 (transponder)
6V (two 3 V lithium battery)
Negligible when not operating, 15mA for transmission
2 sec (radio transmission)
red LED
Member of:
MPSTP2EB_V0.doc
Associated
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PRASTEL MPSTP2EB
Summary of Contents for PRASTEL MPSTP2EB
- Page 1 ENGLISH MPSTP2EB_V0.doc MPSTP2E CAUTION FOR THE USER Any change or modification of the product is forbidden if not expressly approved by the manufacturer 0. DESCRIPTION MPSTP2E is a radio transmitter used with radio receivers of the Multipass and Roll series. It has two pushbuttons being capable to activate two different output channels on a radio receiver working with the same code and the same operating frequency.
- Page 2 ENGLISH MPSTP2EB_V0.doc MPSTP2E 3. HOW TO PROCEED WHEN CHANGING THE BATTERY FIG. 1 HOW TO CHANGE THE BATTERIES: • Loosen screw «A» as shown in Fig. 1. • Open the remote control. • Remove the batteries handling them as shown in Fig. 2. •...
