MONARCH 2 95SEPC1K
Community
Controls
Thank you for choosing a Community Controls product .
Please read this manual carefully before using the product.
Made in Italy. Copyright © 2006 by Community Controls.
CONTENTS
1 - TRANSMITTER OVERVIEW
1A - General information
1B - Technical specifications
1C - Main components
1A - General information
The Community Controls - Monarch 295SEPC1K transmitter is a key
chain style mini transmitter operating at 295 MHz. It has been designed
for use with programmable telephone entry, security , and access control
systems operating with a 295 MHz frequency receiver.
The protocol is ClikCard® compatible and the code sent by the
transmitter includes a 16 bit security code which allows up to 65,536
combinations and 6 bit of facility code for 64 different combinations.
The Community Controls - 295R receiver which operates with this
transmitter has a Wiegand 26 bit and can operate any type of access
control system equipped with the same protocol. The CR 2016 lithium
batteries of the transmitter have a shelf life of about 6 months. The
product fully complies with Part 15 of FCC Regulations and the
European Directives 99/5/CE, 89/336/CEE, 73/23/CEE.
1B - Technical specifications
Operating frequency
Number of keys:
Battery :
Battery life:
Number combinations :
Protocol :
Different Facilities codes
Operating temperature:
Overall dimensions:
Weight:
1C - Main components
Red
LED
Dark grey
case
Fig. 2
295 MHz
1
2 x 3V lithium batteries CR2016
18 ÷ 24 months
65,536
ClikCard® compatible
64
-20°F÷+131°F (-20°C÷+55°C)
2.4"x1.4"x0.51" (61x36x13 mm)
0.49 oz. (14 gr.)
Dark grey
push-button
Key ring
holder
