- Page 1 OMRON AUTOMOTIVE ELECTRONICS KOREA OKA-620R RECEIVER, RF Keyless Entry System...
-
Page 2: Table Of Contents
Table of contents 1. Constitution of the Radio Frequency Keyless Entry system Controller for vehicle --- 1 2. User's manual (provisionally) ----------------------------------------------------------------- 2 3. Specification ------------------------------------------------------------------------------------- 3 4. Features ------------------------------------------------------------------------------------------- 4 5. Derivatives --------------------------------------------------------------------------------------- 4... -
Page 3: Constitution Of The Radio Frequency Keyless Entry System Controller For Vehicle
1. Constitution of the Radio Frequency Keyless Entry System for vehicle The radio frequency keyless entry is a system that it controls locking and unlocking the door and alarm the horn by wireless remote controller. This system consists of three components. The TRANSMITTER is a device that transmits the signal when the button is pressed. -
Page 4: User's Manual (Provisionally)
2. User's manual (provisionally) REMOTE TRANSMITTER You can lock and unlock and alarm the horn your vehicle with the remote transmitter. LOCK When you push the LOCK button, all the doors will lock. You cannot lock any of the doors with the remote transmitter if any door is open or the key is the ignition switch. UNLOCK When you push the UNLOCK button, all the doors will unlock. -
Page 5: Specification
3.2 EEPROM 93C46XXX Type Manufacturer: Seiko. Elec. Memory 1Kbit 8pin Package 3.3 RF Receiver Module Type G8X-28RXIAM26 Manufacturer: OMRON Elec. Local clock frequency 313.85MHz Frequency generation Crystal resonator Modulation Scheme FM (Single Superheterodyne) Bandwidth ±200kHz Carrier Detect Sensitivity 11dBuVemf 4.4 Others Dimension 105mm ×... -
Page 6: Features
.After transmitting , the micro-computer switches stand-by mode by itself. 5. Derivatives OKA-620R is an integrated controller for a car body control, includes the keyless entry receiver. The integrated controller consists of the multiple control functions as follows, centralized door lock, and so on.
